JUKI DDL-5550N Handbook page 87

SUBCLASS MACHINE LIST
Subclass machines
Seams
U10
Basic stitch (universal type)
K10
Covering
1 Stitch length can be adjusted to 4.5mm at the maximum.
U10 (universal type)
This basic model can be used in a broad range of processes
including sleeve-/bottom-hemming for T-shirts and coverings
for sportswear and knitwear.
LIST OF GAUGES
Seams Model name
MF-7822-U10-B48
MF-7823-U10-B56
MF-7823-U10-B64
MF-7823-K10-B56
MF-7822, MF-7823 (August, 2004) 2/2
Model No. Number of
needles
MF-7822-U10-B48 2
MF-7823-U10-B56 3
MF-7823-U10-B64 3
MF-7823-K10-B56 3
2 Differential ratio can be switched by adjustment.
Needle clamp Presser foot asm.
13350509 13376058
13350301 13375050
13350400 13375050
13350301 13375050
1
Number of Needle gauge Stitch
threads (mm) length (mm)
4 4.8 0.9 3.6
5 5.6 0.9 3.6
5 6.4 0.9 3.6
5 5.6 0.9 3.6
3 5mm with top coverstitch, 8mm without top coverstitch.
K10 (covering)
This model is best suited to the covering process for
polo shirts, trainers, sportswear, knit outers, etc.
Covering guard (R) Part No.: 13438007
Covering guard (L) Part No.: 13438106
Throat plate Main feed dog
13354709
13354808
13351200
13352307
2 3
Differential- Presser lifting Max. sewing
feed ratio amount (mm) speed (rpm)
1:0.9 1:1.8
5(8)
(1:0.6 1:1.1)
1:0.9 1:1.8
5(8)
(1:0.6 1:1.1)
1:0.9 1:1.8
5(8)
(1:0.6 1:1.1)
1:0.9 1:1.8
5(8)
(1:0.6 1:1.1)
Differential-feed dog
13431200 13433503
13431200 13433503
13430103 13432109
13430707 13432901
6,500
6,500
6,500
6,500
