Computer-controlled, Eyelet Buttonholing Machine
with Trimmer for Needle and Looper Thread with Gimp
MEB-3200SS
(for men's and ladies' wear)
MEB-3200RS
(for combined use for lateral and longitudinal buttonholing:
for men's and ladies' wear)
MEB-3200JS
(for jeans)
MEB-3200CS
(for cotton pants and working wear)
MEB-3200TS
(for trousers)
● An active tension mechanism (computer-controlled thread tension
mechanism) that electronically controls the needle and looper thread
tensions.
Needle and looper thread tensions can be digitally established on the
operation panel according to sewing conditions.
registered on a pattern-by-pattern basis to easily reproduce the same
sewing conditions.
Thread tensions can be separately established for various sections of a
buttonhole such as eyelet sections and parallel sections.
● The knife is controlled by a stepping motor.
adjustment of the knife pressure on the operation panel to suit the
material to be used, thereby preventing irregular cutting.
Selection between the cut-before knife and cut-after knife can be made
on the operation panel.
● The right and left work clamps are separately driven by independent air
cylinders. With this mechanism, the work clamps reliably clamp
materials of different thicknesses to prevent the materials from flopping.
● JUKI has newly developed a machine head with a shallow recess.
For the efficient sewing of longitudinal buttonholing.
● The computer controlled design eliminates most of the complicated
mechanisms. This dramatically improves maintainability.
SPECIFICATIONS
Model name
Application
Thread trimming style
Stitch system
Max. sewing speed
Sewing length
Needle throwing width
(at the time of delivery)
Taper bar length
Work clamp height
Method for changing stitch shape
Buttonhole cutting method
Feed system
Cloth cutting knife drive system
Needle
(at the time of delivery)
Lubrication
Lubricating oil
Compressed air and air consumption
Power requirement and
power consumption
Dimensions
Total weight
By selecting the left looper and left spreader, the range of stitch bite can be changed to 2.6 4.0mm from 2.0 3.2mm (TS model is excluded)
Data can be
This enables easy
MEB-3200SS MEB-3200RS
For combined use for lateral and
For men's and
longitudinal buttonholing:
ladies' wear
for men's and ladies' wear
Longer remaining thread
1-needle, double chainstitch (with gimp)
10 38mm (with thread trimmer)
10 50mm (in case looper thread trimming device is removed)
2.0 3.2mm
(2.3mm)
By cut-before knife or cut-after or without buttonhole cutting
DO 558
(Nm100) Nm90 Nm110
MEB-3200JS
For jeans
Shorter remaining thread
400 2,200rpm (100rpm step)
Work clamp type S
16 24 (26)mm: optional
Work clamp type M
24 32 (34)mm: standard
Work clamp type L
32 40 (42)mm: optional
The figures in ( ) parentheses are in case of taper bar
2.6 4.0mm
(2.5mm)
0mm, 3 15mm
13mm (max. 16mm)
By selecting a program
Intermittent feed by stepping motor
Vertically driven by stepping motor
DO 558
(Nm120) Nm110 Nm120 (Nm110) Nm110 Nm120 (Nm100) Nm100 Nm110
Automatic (looper and spreader: by an oiler)
JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
0.5MPa (5kgf/F), 6NR/min (8cycle/min)
Single-/3-phase, 550VA
1,060mm (W) 790mm (D) 1,230mm (H)
185kg
MEB-3200SS, 3200RS, 3200JS, 3200CS, 3200TS (September, 2003) 1/4
MEB-3200JS
MEB-3200SS
MEB-3200CS MEB-3200TS
For cotton pants
For trousers
and working wear
Shorter thread
cutting without gimp
1-needle, double
chainstitch
(without gimp)
Work clamp type S
16 24 (26)mm: standard
10 34mm
Work clamp type M
Compensating
24 32 (34)mm: optional
work clamp S, 24mm
Work clamp type L
for eyelet buttonholes:
32 40 (42)mm: optional
standard
2.0 3.2mm 2.0 3.2mm
(2.5mm) (2.3mm)
DO 558 DO 558
9
