EXCHANGING PARTS
● Table of changing gears
Small gear
Set Stitch No.
B2936-761-000
A 54
B 62 B2938-761-000
C 66 B2940-761-000
B2942-761-000
D 70
E 74 B2944-761-000
F 79 B2946-761-000
B2928-761-000
G 83
H 88 B2948-761-000
I 93 B2950-761-000
B2930-761-000
J 100
K 105 B2952-761-000
B2932-761-000
L 110
B2954-761-000
M 115
N 123 B2934-761-000
B2956-761-000
O 130
● Table showing parts used in connection with knives
No. Size
1 6.4mm (1/4")
2 9.5mm (3/8")
3 12.7mm (1/2")
4 14.3mm (9/16")
5 15.9mm (5/8")
6 19.1mm (3/4")
7 22.2mm (7/8")
8 25.4mm (1")
9 31.8mm (1-1/4")
10 34.9mm (1-3/8")
11 38.1mm (1-1/2")
Part No. Stitch No.
345
300
285
268
252
238
225
212
200
190
180
170
160
152
145
Knife
A
Part No.
B2702-047-F00
B2702-047-K00
B2702-047-L00
B2702-047-V00
B2702-047-M00
B2702-047-N00
B2702-047-P00
B2702-047-Q00
B2702-047-S00
B2745-774-00A
B2745-774-00B
Large gear
Stitch No.
B2937-761-000
B2939-761-000
B2941-761-000
B2943-761-000
B2945-761-000
B2947-761-000
B2929-761-000
B2949-761-000
B2951-761-000
B2931-761-000
B2953-761-000
B2933-761-000
B2955-761-000
B2935-761-000
B2957-761-000
Work clamp check
B
Part No.
B1552-781-000-A
B1552-782-000
B1552-783-000
B1552-784-000
Note: Standard model machine is used as the standard for work clamp check and throat plate.
Throat plate
C
Part No.
B2402-771-000
B2402-774-000
