Regularly clean the motor housing using a damp cloth.
u
Do not use any abrasive or solvent-based cleaner.
Regularly open the chuck and tap it to remove any dust
u
from the interior (when fitted).

Protecting the environment

Z
Separate collection. This product must not be
disposed of with normal household waste.
Should you find one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product
z
available for separate collection.
Separate collection of used products and packaging
allows materials to be recycled and used again. Re-use
of recycled materials helps prevent environmental
pollution and reduces the demand for raw materials.
Local regulations may provide for separate collection of
electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker office at the
address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Batteries
Z
At the end of their useful life, discard batteries with
due care for our environment:
Do not short-circuit the battery terminals.
u
Do not dispose of the battery(s) in a fire as this may result
u
in a risk of personal injury or an explosion.
Run the battery down completely, then remove it from the tool.
u
Batteries are recyclable. Place the battery(s) in a suitable
u
packaging to ensure that the terminals cannot be
short-circuited. Take them to any authorised repair agent
or a local recycling station.
8
Technical data
Voltage
No-load speed
Hard stall torque
Max. torque
Bit holder
Weight
Battery
Voltage
Battery type
Capacity
Charger
Input voltage
Output voltage
Current
Approx. charging time
Weight
Level of sound pressure according to EN 60745:
Sound pressure (L ) 58.9 dB(A), uncertainty (K) 3 dB(A)
pA
Sound power (L ) 69.9 dB(A), uncertainty (K) 3 dB(A)
WA
Vibration total values (triax vector sum) according to EN 60745:
Drilling into metal (a ) 0.979 m/s
h, D
Screwdriving without impact (a
uncertainty (K) 1.5 m/s
KC460LN (H1)
V 3.6
DC
min 180
-1
Nm 7.7
Nm 3.2
mm 6.35 (1/4")
kg 0.4
V 3.6
Li-Ion
Ah 1.1/1.3
905450XX
V 230
AC
V 9
DC
mA 100
h 12
kg 0.4
, uncertainty (K) 1.5 m/s
2
) 0.247 m/s ,
2
h, S
2
2
