Figure 3
yellow) Fuel Burner HVAC system connecting to an IMT base plate.
Figure 3 Single/Dual Stage Fuel Burner HVAC Connections
The wiring colors shown above are examples of commonly used colors and may
differ depending on the HVAC wiring that is used.
Note
Proliphix Internet Managed Thermostat (IMT) Installation Guide
Part No. 600-03100-000, Rev. 4
shows an example of a single-stage (shown in blue) and dual-stage (shown in
1
C RH W1
Common
1st Stage
Heat Control
24VAC
Source
Installing and Wiring the Thermostat
IMT Base Plate
W2 Y1
1st Stage
2nd Stage
Heat Control Cool Control
HVAC System
Y2 G
2nd Stage Fan
Cool Control Control
