Installing the Base Plate

Perform the following steps to mount the thermostat base plate on the wall:
Review the
1
appropriate location on the wall. Ensure the location allows you to access and pull the
wires through the opening in the base plate.
There are four mounting holes on the backplate that allow for mounting in a single
vertical or horizontal oriented single gang electrical box using only two screws. If
Note
you are installing the backplate on drywall directly, then use three screws.
Using a pencil, mark the center of the screw holes on the left and right side, and
2
bottom center of the base plate.
Remove the base plate from the wall and drill two or three holes at the marked
3
locations: for drywall, drill 3/16" holes; for plaster, drill 7/32" holes.
Gently tap the wall anchors (included in the packaging) into the drilled holes until
4
they are flush with the wall.
Pull the wires through the base plate and position the base plate over the screw holes.
5
Attach the base plate to the wall using three 1" screws (included in the packaging).
6

HVAC System Power Configuration

The Proliphix thermostat contains jumpers to configure the HVAC power settings.
The power settings determine which HVAC power source (RH or RC) is configured to
turn on each HVAC system (cool, heat, and fan). Most applications use only RH
power. The Proliphix thermostat is shipped from the factory with the RH and RC
jumpered together.
Table 1
Proliphix Internet Managed Thermostat (IMT) Installation Guide
Part No. 600-03100-000, Rev. 4
Installation Guidelines
lists the possible HVAC power configurations.
Installing and Wiring the Thermostat
on page 1 and position the base plate in an
