MESSAGE ERROR
The motor spins into an opposite direction.
E7 DIRECTION
The motor hall IC is an inferior product or broke
down.
The motor is not normally connected.
MOTOR
E8
The motor does not work.
ERROR
(The motor is an inferior product or broke down.)
SENSOR The water level sensor is an inferior product.
E9 PRESSURE
ERROR
The thermistor dry is an inferior product or
THERMISTOR
broke down.
H1 (TEMP. SENSOR)
The thermistor dry is not connected normally.
DRY ERROR
The thermistor wash is an inferior product or
broke down.
THERMISTOR
H2
WASH ERROR
The thermistor wash is not connected normally.
The fan motor does not spin with the proper rpm.
(The fan motor is an inferior product or broke down.)
THERMISTOR
DRY
H3
OVERHEATING
ERROR
The thermistor dry is an inferior product or
broke down.
THERMISTOR The heater worked without the water in the tub.
WASH
The thermistor wash is an inferior product or
H4
OVERHEATING
broke down.
ERROR
WATER TEMP. The water temp. is over 45°C in delicate & wool
H5
ERROR course.
The heater wash dose not work.
HEATER
(The water temp. doesn't rise over 2°C during
H6 WASH
15min.)
ERROR
HEATER The heater dry dose not work.
H7
DRY ERROR (The water temp. doesn't rise over 3°C during 8min.)
The heater worked without the water in the tub.
HEATER
WASH
H8
OVERHEATING
ERROR
The drain pump filter is clogged.
The drain pump does not work during spin.
PUMP FILTER
PFE
The large amount of detergent was used.
ERROR
The drain hose is placed higher than 1m above the
floor.
CAUSE
Change the PCB ASS'Y or the
motor.
Change the motor hall IC or the
motor.
Check the connector of the motor.
Change the motor.
Change the water level sensor.
Change the thermistor dry.
Check the connector of the thermistor
dry.
Change the thermistor wash.
Check the connector of the thermistor
wash.
Change the fan motor.
Change the thermistor dry.
Check the water level.
Change the thermistor wash.
Change the thermistor wash.
Change the heater wash.
Change the heater dry.
Check the water level and the heater
wash.
Clean the drain pump filter.
Change the drain pump.
Use the proper amount of detergent.
Place the drain hose 1m below the
floor
45 45
SOLUTION
