Daewoo DWC-LU1011 Service Manual page 11

No. PARTS NAME
B01 NOZZLE *T
B02 NOZZLE *U
B03 BOX INLET
B04 HOSE INLET
B05 CLAMP AS
B06 VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
VALVE INLET
B07 HOSE WATER SUPPLY
B08 HOSE WATER SUPPLY
B09 CLAMP HOSE
VALVE INLET
B10
VALVE INLET
VALVE INLET
B11 HOSE WATER SUPPLY
B12 HOSE WATER SUPPLY
PIPE JOINT I
B13
PIPE JOINT(HOSE INLET)
B14 Unit Steam AS
CODE
3618111100 PP
3618111000 PP
3610526500 PP
3613274600 EPDM
3611203200 ID=60, WIRE+GUIDE+BOLT+NUT
36154L3A00 220-240V.VDE.BITRON.4WAY V1:DRY V2:STEAM
36154L3B00 220-240V.VDE.BITRON.3WAY V2:STEAM
36154L3D10 120V.BITRON.4WAY V1:DRY V2:STEAM
3615414900 220-240V 2-WAY PP/BRACKET
3615415050 220~240V,3WAY,RINSE GUIDE,PP/BRACKET
3615415070 100~130V,3WAY,RINSE GUIDE,PP/BRACKET
3615416820 220-240V.VDE.BITRON.2WAY
3615416821 220-240V.VDE.BITRON.2WAY + DR TECH INSPECTION COST
3615416720 220-240V60HZ.VDE.BITRON.1WAY
3615416970 UL 220~240V,BITRON 3WAY V1,V3 WITH CONTROL PC
3613270900 EPDM ID9.5 OD14.5, WASHING
3613270900 EPDM ID9.5 OD14.5, PRE.WASH
3611205800 100H, ID=13.8 W=10.0 0.9T
3615414800 220-240V 1-WAY HOT PP-BRACKET
3615414820 220-240V 1-WAY HOT PP-BRACKET 180
3615415700 100-130 1-WAY HOT PP-BRACKET
3613270900 EPDM ID9.5 OD14.5, HOT
3613270900 EPDM ID9.5 OD14.5, STEAM
3614426000 PP
3614413300 PP , T-type
36189M2U00 L-SERIES STEAM UNIT 900W
9
SPECIFICATIONS Q'TY REMARK
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
10
1
1
1
1
1
1
1
1 option
