Service Manual

Drum Washing Machine
: DWC-1011W
Model
• Caution:
In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
April 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWC-1011W and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DWC-1011W

Summary of Contents for Daewoo DWC-1011W

  • Page 1: Service Manual

    Service Manual Drum Washing Machine : DWC-1011W Model • Caution: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    DRUM WASHING MACHINE SERVICE MANUAL 1. WHAT IS DRUM WASHING MACHINE? ........1 2. WASHER SpECIfICATIoN ............3 3. pARTS lIST by ASS'y ..............4 4. CoNTRol pART fUNCTIoN SpECIfICATIoN ......17 5. ElECTRoNIC fIElD pARTS lIST AND SpECIfICATIoN ..32 6. WIRING DIAGRAM ..............33...

  • Page 3: What Is Drum Washing Machine

    1. WHAT IS DRUM WASHING MACHINE? 1. Drum Washing Machine Water consumption is reduced by using the power of the laundry falling (free-fall) created when rotating the drum. With temperature control system, this drum washing machine saves energy and improves washing performance at the same time.
  • Page 4 3. Power System LAUNDRY BLDC Pump Drainage • DD Control: Direct drive type of direct connection between drum and motor • Rotation by powerful high-performance BLDC motor...

  • Page 5: Washer Specification

    2. WASHER SpECIfICATIoN 1. Product Specification ■ DWC-1011W MODEL DWC-LU1011/1211 DWD-LU1011/1211 DWC-LD1411/1611 DWD-LD1411/1611 Dimension (mm) 600 X 645 X 850 Maximum mass of textile (kg) 9 Kg Unit Weight (net/gross) 78/82 71/75 76/80 69/73 Standard Water Consumption 65 ℓ DWC(DWD)-LU10XX : MAX 1000...

  • Page 6: Parts List

    Parts List 2. pANEl f AS ■ Panel Front...
  • Page 7 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK pANEl fRoNT AS 361- - - - - - - D-LU1221 pANEl fRoNT AS 36142T2100 4x16 SUS 430 bUTToN fUNCTIoN 3616644400 bUTToN opTIoN 3616644700 HolDER lED fUNCTIoN 3613058500 HIpS pCb f AS PRPSSW- - - - D-LU1221 HolDER lED DISplAy 3613058600...
  • Page 8 3. INlET boX AS...
  • Page 9 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK NoZZlE *T 3618111100 NoZZlE *U 3618111000 boX INlET 3610526500 HoSE INlET 3613274600 EpDM ClAMp AS 3611203200 ID=60, WIRE+GUIDE+bolT+NUT VAlVE INlET 3615416821 220-240V.VDE.BITRON. HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, WASHING HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, pRE.WASH ClAMp HoSE 3611205800...
  • Page 10 5. DooR AS ■ 2st Model...
  • Page 11 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK DooR AS 361- - - - - - - fRAME DooR 0 36122UDC00 pRoTECToR GlASS 3618345600 TR-ABS DooR GlASS 361A113300 GlASS fRAME DooR 1 36122UDD00 HINGE DooR 3612903800 AlDC CAp HINGE DooR 3610916500 SCREW TAppING 7115402029 T1S flT 4*20 STS430 NATURE...
  • Page 12 7. TUb ASSy(DD MoToR)
  • Page 13 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK bAlANCER WEIGHT l 3616110600 PP, D-LU1011, 6.6KG SpECIAl SCREW 3616029400 SWCH 8.5X30 bAlANCER WEIGHT R 3616110500 PP, D-LU1011, 6.6KG ClAMp GASKET AS 3611207000 C-LU1011 GASKET 3612325300 EPDM , WASH , D-LU1011 WASH GASKET 3612325400 EPDM , DRY , C-LU1011 NoZZlE SHoWER 3618111200...
  • Page 14 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK bAlANCER WEIGHT T 3616110400 PP, C-LU1011, 2.48KG bAlANCER WEIGHT T(WASH) 3616110700 PP, D-LU1011, 2.48KG WASH SpECIAl SCREW 3616029400 SWCH 8.5X30 ClAMp HoSE 3611204700 SpECIAl SCREW 3616007400 T2S TRS 4X10+24 opTIoN UNIT bUbblE GENERAToR 36189l4177 HIGH,pAD b,bl/WH,320,Rp4,GUIDE o,SpoNGE 200 opTIoN HoSE VENT...
  • Page 15 8. DUCT b...
  • Page 16 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK DUCT b UppER 361A202400 AlCoSTA SCREW TAppING 7122401411 T2S TRS 4X14 MfZN SCREW TAppING 7112401208 T1 TRS 4X12 SUS HEATER DRy 3612801400 230V 2.1KW 25.19oHM 6.1W/SQ INColoy800 1R1A034002 pACKING THERMoSTAT 3614009900 SILICON, DWD-100DR SWITCH THERMoSTAT 3619046500 oN120°C off150°C 230V 15A VDE DUCT b loWER...
  • Page 17 9. CAbINET AS...
  • Page 18 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK CAbINET 3610813300 SGCC 0.8T,l'S fRAME loWER 36122UD700 SGCC 1.2T fRAME Top *l 36122UDA00 SGCC 1.6T fRAME Top *R 36122UDb00 SGCC 1.6T bASE U l 3610393800 SGCC T2.0 bASE U R 3610393900 SGCC T2.0 lEG ADJUST AS 3617703811 CHINA PARTS, DWD-900W MAIN pCb AS...

  • Page 19: Control Part Function Specification

    4. CoNTRoL pART fUNCTIoN SpECIfICATIoN 1. SEQUENCE CHART Cotton/Noraml Synthetic Delicate Intensive Division Time Small Middle Small Small Middle Sensing 20sec ▒ Water Supply 2min ▒ 10min pre. Wash 8min ▒ Drain 1min ▒ Balancing Spin 2min ▒ Mid. Spin 3min ▒...
  • Page 20 Quick 20 Sports Wear Tub Clean Drain Division Time Small Small Small Small Soal 30min ▒(1min) ▒ ▒ Water Supply 2min 60min 50min Washing 1 35min (Heating) 30min 5min ▒ 13min ▒ ▒ Washing 2 10min ▒(3min) ▒ ▒ 4min Drain 1min Balancing Spin...
  • Page 21 2. Skill of each Sequence 2-1. Washing Sequence 1) Washing Sequence part Time Part LOAD SENSING Water Level Course HEATING Washing Main Decision Level Decision Level Decision Level Decision Level 8min Soak High 30min ① Prewash and Soak working previous main washing. ②...
  • Page 22 ① Washing Heater isn't reworking after reach decision temperature. ② Normal Course + 40°C include 7 min that heater does not working. ③ If Set up Normal + 40°C then main washing time is 40 min. ④ If LS value is more than 360, 1 hour add in Washing Time. 3) Electric Current Time of Washing Motor Part Water...
  • Page 23 2-2. Rinse Sequence 1) Water Supply Sequence part level height(mm) Water Level 24.32 Rinse water level ① Only cold water supply in Rinse Sequence ② In last Rinse Sequence, use fabric conditioner by open water valves. 2) Re-Water Supply ① After 1 min in Rinse Sequence, check water level and work Re-Water Supply. 3) Rinse Sequence part MOTOR On/OFF (sec)
  • Page 24 2-3. Spin Sequence 1) Drain ① It follows Drainage Sequence. 2) Balance Spin ① If Unbalance Check pass, Start R-Spin. ② B-Spin is Until Unbalance check section, 350 r.p.m 3) R(Real) Spin ① From end of B-Spin to end of Spin Sequence is R Spin. ②...
  • Page 25 2-5. Drying Sequence 1) consist of drying sequence. ex) select normal drying (Total spend time 2:30) ➞ ➞ ➞ Drain(1min) Drying(144min) COOLING(5min) End(10sec) Crease Care(30min) ➞ → Not Displayed 2) Electric Current Time of Dry Sequence. Heater Off/On Crease Care Drying COOLING Wrinkle Free...
  • Page 26 3. Main Function of PCB Program 3-1. LOAD SENSING 1) Deciding the water level ① Normal, White, Eco-White Course will be followed by this process. ② Check the water level with dry laundry at the starting wash. ③ Check the water level by using motor output data during 20 sec, 65rpm. 2) Deciding Spin Starting Step.
  • Page 27 3-3. DOOR S/W 1) The working principle of Door S/W ① Door Locking Bimetal on (3 sec) → solenoid (supply 20msec pulse 2 times) ② Door Unlocking Bimetal off → solenoid(supply 20msec pulse, until lock) ③ After door locking all parts can work nomally. ④...
  • Page 28 5. TEST MoDE 5-1. Metodo de prueba La PCB y otras partes electrónicas puedes ser revisadas sin llenar la tina y conocer su estado, normal o no. 1) Procceso Presione "Power" → presione y sostenga "WASH", presione 3 veces "SPIN" → 'b04' se mostrará en el display →...
  • Page 29 6-1. Error Display 6-1. IE (Input Error) - Error in water supply 1) Conditions of Occurrence ① In case the designated water level is not reached in 5 minutes during water supply or re-supply 2) All LEDs are turned off and 'IE' blinks in18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 30 6-4. LE (Lock Error) - Door opening error 1) Conditions of Occurrence ① When intending to begin cycle by pressing start/ temporary stop button while door is opened 2) All LEDs are turned off and 'LE' blinks in 18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 31 6-7. E4 - Water leakage during washing 1) Conditions of Occurrence ① In case water level falls below re-supply even after 15 times of re-supply prior to finishing of water heating 2) All LEDs are turned off and 'E4' blinks in 18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 32 6-9. Motor-related Error 1) E5 (DC-Link High Voltage) Error ① In case DC-link voltage to IPM increases to 450V or higher ② Motor operation is stopped and 'E5' is shown in display window. ③ Error buzzer alarm is sounded for 10 seconds per every 10 minutes. ④...
  • Page 33 3) H5 Error - Water temperature error in wool/ delicate course ① In case water temperature in wool/ delicate course is 45℃ or higher ② Error buzzer alarm is sounded for 10 seconds per every 10 minutes. ③ Error display is cleared when turning off/ on power. 4) H6 Error - Abnormality in washing heater ①...

  • Page 34: Electronic Field Parts List And Specification

    5. ELECTRoNIC fIELD pARTS LIST AND SpECIfICATIoN classification part Name Part Code SPECIFICATIONS Q'ty SWITCH DooR loCK 3619047200 Common DL-S1.250V16A.BITRON Valve Inlet 3615414820 Common 220-240V 1-WAY HOT PP-BRACKET Valve Inlet 36154l3b00 220-240V.VDE.BITRON.3WAY V2:STEAM Reactor AS 3615800100 Common DWD-800W RT--046B Valve Inlet 36154l3A00 220-240V,4WAY,Steam&Dry 36189M2T00...

  • Page 35: Wiring Diagram

    6. WIRING DIAGRAM ■ DWC-LD'S...
  • Page 36 ■ DWC-LU'S...
  • Page 37 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.p.o. boX 8003 SEoUl, KoREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Oct. 2009...
