Daewoo DWC-LU1011 Service Manual page 19

No. PARTS NAME
D01 BALANCER WEIGHT L
D02 SPECIAL SCREW
D03 BALANCER WEIGHT R
D04 CLAMP GASKET AS
D05 GASKET
D06 GASKET
D07 NOZZLE SHOWER
D08 CLAMP GASKET BUSHING
D09 SPECIAL SCREW
D10 DUCT B AS
D11 HOSE DRAIN *I
D12 CLAMP AS
D13 CLAMP HOSE
D14 CLAMP HOSE
D15 AIR TRAP
D16 HOSE AIR(PRESSURE)
D17 DAMPER FRICTION
D18 DAMPER PIN
D19 TUB *F (FRONT)
D20 SPRING SUSPENSION
D21 SPECIAL SCREW
D22 SPECIAL SCREW
D23 LIFTER WASH
D24 SCREW TAPPING
D25 DRUM SUB AS
D26 SPIDER AS
D27 WATER SEAL
D28 SEALING TUB
D29 FIXTURE HEATER
D30 BEARING INNER
D31 UNIT MOTOR UNIVERSAL
D32 BALANCER WEIGHT LOWER
D33 SPECIAL SCREW
D34 SPECIAL SCREW
D35 DAMPER FRICTION
D36 DAMPER PIN
D37 TUB REAR AS
D38 BALANCER WEIGHT T
D39 BALANCER WEIGHT T(WASH)
D40 SPECIAL SCREW
D41 CLAMP HOSE
D42 SPECIAL SCREW
D43 UNIT BUBBLE PUMP AS
D44 HOSE VENT
D45 BEARING OUTER
D46 HEATER WASH
D47 PIPE DUCT AS
D48 PULLEY
D49 SPECIAL BOLT AS
D50 BELT V
CODE SPECIFICATIONS
3616110600 PP, D-LU1011, 6.6KG
3616029400 SWCH 8.5X30
3616110500 PP, D-LU1011, 6.6KG
3611207000 C-LU1011
3612325300 EPDM , WASH , D-LU1011
3612325400 EPDM , DRY , C-LU1011
3618111200 PP
3611206800 GI 1.2T
3616029810 SWCH 6.5X45
3610DUTL00 C-L E
3613275200 EPDM D-LU1011
3611203210 ID=61, WIRE+GUIDE+BOLT, GS
3611204700 D26
3611201401 HSW3,YW,D2.6,ID36,W44.5
361A500101 PP
3613266930 ID=4,OD=8, L=680MM(L-SERIES)
361A700110 70N AKS ST=170-260 DL=197.5 LOW NOISE
361A700200 AKS D=14.5
3618830000 FRPP, C-LU1011
3615116800 KGF
3616029800 SWCH 6.5X30
3616029500 SUS430 8*25
361A401300 PP,1PIECE,TWIST
7122401408 T2S TRS 4X14 SUS,STS
3617012600 D-LU1011
361A301200 D-LU1011
361A600100 NBR
3612321601 EPDM L1600(-0~ +10)
3612006700 SUS
3616303100 6206Z
36189L4H10 DC220/50 G&J 2P PI340 45T(CCA)
3616110300 PP, D-LU1011, 3.5KG
3616029400 SWCH 8.5X30
3616062800 SWRCH18A 7.4*25.5
361A700130 60N AKS ST=170-260 DL=197.5 LOW NOISE
361A700200 AKS D=14.5
36100T1400 D-LU1011
3616110400 PP, C-LU1011, 2.48KG
3616110700 PP, D-LU1011, 2.48KG
3616029400 SWCH 8.5X30
3611204700 D26
3616007400 T2S TRS 4X10+24
36189L4120 220-240V DBK-240DB RP CHSHION
3613267100 EPDM
3616303200 6205Z
3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA
3614414001 C-L PIPE DUCT+HOSE+CLAMP
3618434100 ALDC
3616029600 SWCH 10*30,F/L BOLT S.P/W SEAL LOCK
3616591120 GATES 4PJ1175 BUTADIENE RUBBER
17
Q'TY REMARK
1
8
1
1
1 FOR WASH
1 FOR DRY
1
1 FOR DRY
4
1 FOR DRY
1
1
1
1
1
1
2
2
1
2
14
3
3
3
1
1
1
1
1
1
1
1
2
2
2
2
1
1 FOR DRY
1 FOR WASH
2
1
2 OPTION
1 OPTION
1
1
1
1 FOR DRY
1
1
1
