Daewoo DWC-LU1011 Service Manual page 21

No. PARTS NAME
D01 BALANCER WEIGHT L
D02 SPECIAL SCREW
D03 BALANCER WEIGHT R
D04 CLAMP GASKET AS
D05 GASKET
D06 GASKET
D07 NOZZLE SHOWER
D08 CLAMP GASKET BUSHING
D09 SPECIAL SCREW
D10 DUCT B AS
D11 HOSE DRAIN *I
D12 CLAMP AS
D13 CLAMP HOSE
D14 CLAMP HOSE
D15 AIR TRAP
D16 HOSE AIR(PRESSURE)
D17 DAMPER FRICTION
D18 DAMPER PIN
D19 TUB FRONT
D20 SPRING SUSPENSION
D21 SPECIAL SCREW
D22 SPECIAL SCREW
D23 LIFTER WASH
D24 SCREW TAPPING
D25 DRUM AS
D26 SPIDER AS
D27 WATER SEAL
D28 SEALING TUB
D29 FIXTURE HEATER
D30 BEARING INNER
D31 DAMPER FRICTION
D32 DAMPER PIN
D33 TUB REAR AS
D33-1 TUB REAR
D33-2 BEARING HOUSING
D34 BALANCER WEIGHT T
D35 BALANCER WEIGHT T(WASH)
D36 SPECIAL SCREW
D37 CLAMP HOSE
D38 SPECIAL SCREW
D39 UNIT BUBBLE GENERATOR
D40 HOSE VENT
D41 BEARING OUTER
D42 HEATER WASH
HEATER WASH
HEATER WASH
HEATER WASH
D43 PIPE DUCT AS
D44 UNIT STATOR BLDC
UNIT STATOR BLDC
D44-1 HALL IC HOLDER AS
D45 SPECIAL BOLT AS
UNIT ROTOR BLDC
D46
UNIT ROTOR BLDC
D47 SPECIAL BOLT AS
CODE SPECIFICATIONS
3616110600 PP, D-LU1011, 6.6KG
3616029400 SWCH 8.5X30
3616110500 PP, D-LU1011, 6.6KG
3611207000 C-LU1011
3612325300 EPDM , WASH , D-LU1011
3612325400 EPDM , DRY , C-LU1011
3618111200 PP
3611206800 GI 1.2T
3616029810 SWCH 6.5X45
3610DUTL00 C-L E
3613275200 EPDM D-LU1011
3611203210 ID=61, WIRE+GUIDE+BOLT, GS
3611204700 D26
3611201401 HSW3,YW,D2.6,ID36,W44.5
361A500101 PP
3613266930 ID=4,OD=8, L=680MM(L-SERIES)
361A700110 70N AKS ST=170-260 DL=197.5 LOW NOISE
361A700200 AKS D=14.5
3618830000 FRPP, C-LU1011
3615116800 KGF
3616029800 SWCH 6.5X30
3616029500 SUS430 8*25
361A401300 PP,1PIECE,TWIST
7122401408 T2S TRS 4X14 SUS,STS
3617012500 D-LU1011
361A301200 D-LU1011
361A600100 NBR
3612321601 EPDM L1600(-0~ +10)
3612006700 SUS
3616303100 6206Z
361A700130 60N AKS ST=170-260 DL=197.5 LOW NOISE
361A700200 AKS D=14.5
36100T1400 D-LU1011
3618830100 FRPP, C-LU1011
3616305000 ALDC, D-LU1011
3616110400 PP, C-LU1011, 2.48KG
3616110700 PP, D-LU1011, 2.48KG
3616029400 SWCH 8.5X30
3611204700 D26
3616007400 T2S TRS 4X10+24
36189L4177 HIGH,PAD B,BL/WH,320,RP4,GUIDE O,SPONGE 200
3613267100 EPDM
3616303200 6205Z
3612802400 220V 2KW.1R0A721001.RW8TF.IRCA,NPB
3612802420 240V 2KW.1R0A721003.RW8TF.IRCA
3612802440 120V 1KW.1R0A721005.RW8TF1PE.IRCA
3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA
3614414001 C-L PIPE DUCT+HOSE+CLAMP
36189L6200 AL,30T(28T),NMT
36189L620A AL,DON1300W 30T 36POLE,NMT,PBT
3616D01000 DRUM STATOR PCB HOLDER AS(SVC),NMT
3616063400 SWCH M8 + SILOCK
36189L6300 L'SERIES, NMT
36189L6300 DON1300W SR-FERRITE12,30~32T,NMT
3616029620 SWCH 10*30 S/W P/W NON-SEAL LOCK
19
Q'TY REMARK
1
8
1
1
1 FOR WASH
1 FOR DRY
1
1 FOR DRY
4
1 FOR DRY
1
1
1
1
1
1
2
2
1
2
14
3
3
3
1
1
1
1
1
1
2
2
1
1
1
1 FOR DRY
1 FOR WASH
2
1
2 OPTION
1 OPTION
1
1
1
1
1
1
1
1 ~20091211(changed)
1 20091211~
1
6
1 ~20091211(changed)
1 20091211~
1
