DS7400XiV4-EXP | Wireless Reference Guide | 2.0
2.0 Programming the Control
Panel
2.1

RF Receiver Setup

2.1.1

Address

Each DS7400Xi Control Panel can accept up to two
receivers. The appropriate receiver address (#1 or #2)
is selected at the receiver. The default setting is #1. Use
Setting #1 if this is the only receiver on the control
panel. Use Setting #2 if a second receiver is used. Refer
to the receiver's documentation for configuration
information.
2.1.2

Supervision

The receiver expects to receive periodic status from
each installed transmitter, and reports to the control
panel when it has not heard from a specific transmitter
for the interval selected at the receiver (typically 12 or
4 hours). Refer to the receiver's documentation for
configuration information.
2.2

Receiver Programming

2.2.1

Number of Receivers

•
Address: 2731
•
Data Digits:
•
Data Digit 1: ____ (refer to Table 2);
default = 0
•
Data Digit 2: ____ (refer to Table 3);
default = 0
•
Selections: 0 to 9; *0 to *3 (hexadecimal values
that display as A to D respectively at the keypads)
Program the control panel for the number of receivers
used, and which zones are assigned to each receiver.
Data Digit 1 defines if there are 0, 1, or 2 receivers.
Data Digit 2 defines the zones covered by Receiver #1
and Receiver #2. If there is only one receiver, Data Digit
2 must be 0. If two receivers are programmed, Data
Digit 2 should not be 0.
Do not program two receivers if you are not
programming zones to both receivers. Also,
do not install a second receiver without first
programming it properly.
Bosch Security Systems | 6/05 | 4998154962B

Programming the Control Panel

Table 2: Address 2731, Data Digit 1
Number of Receivers Options
No Receiver
One Receiver
Two Receivers
Table 3: Address 2731, Data Digit 2
Select Option
One receiver
Receiver #1 = Zones 137 to 144
Receiver #2 = Zones 145 to 248
Receiver #1 = Zones 137 to 152
Receiver #2 = Zones 153 to 248
Receiver #1 = Zones 137 to 160
Receiver #2 = Zones 161 to 248
Receiver #1 = Zones 137 to 168
Receiver #2 = Zones 169 to 248
Receiver #1 = Zones 137 to 176
Receiver #2 = Zones 177 to 248
Receiver #1 = Zones 137 to 184
Receiver #2 = Zones 185 to 248
Receiver #1 = Zones 137 to 192
Receiver #2 = Zones 193 to 248
Receiver #1 = Zones 137 to 200
Receiver #2 = Zones 201 to 248
Receiver #1 = Zones 137 to 208
Receiver #2 = Zones 209 to 248
Receiver #1 = Zones 137 to 216
Receiver #2 = Zones 217 to 248
Receiver #1 = Zones 137 to 224
Receiver #2 = Zones 225 to 248
Receiver #1 = Zones 137 to 232
Receiver #2 = Zones 233 to 248
Receiver #1 = Zones 137 to 240
Receiver #2 = Zones 241 to 248
EN | 5
Value
0
2
4
Value
0
1
2
3
4
5
6
7
8
9
*0
*1
*2
*3
