DS7400XiV4-EXP | Wireless Reference Guide | 5.0
5.3
Assign Keyfobs to an Area
Each keyfob must be assigned to one or all areas. If one of the "All Partitions" options was selected for the zone
(refer to Section 5.2 Program a Zone), you do not need to assign an area to the zone.
The area assignment for odd numbered zones is programmed into the first data digit of these addresses. The area
assignment for even numbered zones is programmed into the second data digit.
For partition assignment addresses, refer to Section 3.4 Assign an Area (Partition) to the Zone of this Guide, or refer to
the DS7400Xi-EXP Reference Guide (P/N: 4998154963).
•
Addresses: 0355 to 0410
•
Data Digits:
•
Data Digit 1: ____ (refer to Table 32; default = 0; applies to odd-numbered zones)
•
Data Digit 2: ____ (refer to Table 32; default = 0; applies to even-numbered zones)
•
Selections: 0 to 7
5.4
Program Wireless Keyfobs
When the Keyfob Zone Programming (Addresses 0167-0278) and Keyfob Partition Assignment Programming
(Addresses 0355 to 0410) is completed, the wireless keyfobs can be programmed into the system. Refer to Section
6.0 Devices for programming the keyfobs.
Bosch Security Systems | 6/05 | 4998154962B
Table 32: Assigning Keyfobs to a Partition (Address
0355 to 0410, Data Digits 1 & 2)
Select Option
Belongs to Partition 1
Belongs to Partition 2
Belongs to Partition 3
Belongs to Partition 4
Belongs to Partition 5
Belongs to Partition 6
Belongs to Partition 7
Belongs to Partition 8
Adding Keyfobs
Value
0
1
2
3
4
5
6
7
EN | 22
