On-Board Output Area Assignment and Chirp Control (Optional)

On-board outputs can be assigned to follow the Option Key in one or all areas in the Output Area Assignment
Addresses 2737 to 2738.
On-board outputs can also be programmed to "chirp" (a 1/2 second sounder output when the controlpanel is
armed, or two 1/2 second sounder outputs when the control panel is disarmed).
•
Addresses: 2737 to 2738
•
Data Digits:
•
Data Digit 1: ____ (refer to Table 23; refer to Table 25 for defaults)
•
Data Digit 2: ____ (refer to Table 23 for Address 2737 Data Digits 1 and 2; refer to Table 23 for Address
2738 Data Digit 1 and Table 24 for Address 2738 Data Digit 2; refer to Table 25 for defaults)
•
Selections: 0 to 8
Table 23: Address 2737 to 2738, Data Digit 1,
and Address 2737 Data Digit 2
Select Option
Belongs to Partition 1
Belongs to Partition 2
Belongs to Partition 3
Belongs to Partition 4
Belongs to Partition 5
Belongs to Partition 6
Belongs to Partition 7
Belongs to Partition 8
Follows all Partitions
Bosch Security Systems | 6/05 | 4998154962B
Adding RF3341 Keypads
Table 24: Address 2738, Data Digit 2
Chirp Options
Chirp Disabled
Value
Bell Output
0
Programmable Output 1
1
Programmable Output 2
2
3
Table 25: Address 2734 to 2738 On-Board
4
5
6
7
Output
8
Alarm
Programmable Output 1
Programmable Output 2
Output Defaults
Address
2737 DD1
2737 DD2
2738 DD1
EN | 18
Value
0
1
2
3
Default
8
8
8
