HP StorageWorks XP12000 User Manual

External storage xp
Hide thumbs Also See for StorageWorks XP12000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual, User Manual
HP StorageWorks

External Storage XP user guide

XP12000
XP10000
SVS200
Part number: T1706-96005
Fifth edition: June 2006

Advertisement

Table of Contents
loading

Related Manuals for HP StorageWorks XP12000

Summary of Contents for HP StorageWorks XP12000

  • Page 1: External Storage Xp User Guide

    HP StorageWorks External Storage XP user guide XP12000 XP10000 SVS200 Part number: T1706-96005 Fifth edition: June 2006...
  • Page 2 The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Limitations on External Storage XP operations..........32 Combining External Storage XP with other HP StorageWorks products ......37 Using external LUs for Auto LUN XP operations .
  • Page 4 In another example, Company B uses the following storage tiers: ..... . 47 To partition cache for external storage:......... 47 Determining the number and size of needed partitions .

  • Page 5: External Storage Xp User Guide

    Path status and examples of recovery procedures (XP512/XP48 Disk Arrays) ....122 Connecting HP 200 Storage Virtualization System as external storage ......123 Path status and examples of recovery procedures (SVS200) .
  • Page 6 Index ............145 Figures External Storage XP concept .

  • Page 7: External Storage Xp User Guide

    Recommended individual CLPR cache size for external storage on open systems ....48 Recommended individual CLPR cache size for external storage on HP storage virtualization systems . . . 48 External array status values .

  • Page 9: About This Guide

    HP Array Configuration Utility User Guide (for HP StorageWorks Modular Smart Arrays) You can find the above documents from the Manuals page of the HP Business Support Center web site: http://www.hp.com/support/manuals. In the Storage section, click Storage array systems, and then select your product.

  • Page 10: Document Conventions And Symbols

    Error messages • Operating system type and revision level • Detailed, specific questions For continuous quality improvement, calls may be recorded or monitored. Subscription service HP recommends that you register your product at the Subscriber’s Choice for Business web site: http://www.hp.com/go/e-updates.

  • Page 11: Hp Web Sites

    After registering, you will receive e-mail notification of product enhancements, new driver versions, firmware updates, and other product resources. HP web sites For additional information, see the following HP web sites: • http://www.hp.com • http://www.hp.com/go/storage • http://www.hp.com/service_locator • http://www.hp.com/support/manuals • http://www.hp.com/support/downloads •...

  • Page 13: Overview Of Connecting External Arrays

    Flex Copy XP is another HP StorageWorks product that copies user data between an LU on a local array and an LU on an external storage device. For a detailed description of Flex Copy XP, see the HP StorageWorks Flex Copy XP user guide.

  • Page 14: External Storage Xp Concept

    Figure 1 illustrates a local array and an external array that are connected using External Storage XP and Fibre Channel hardware. In Figure 1, the external array is connected to the external port of the local array via a switch (or hub) using a Fibre Channel interface. External is a local array port attribute used for External Storage XP.

  • Page 15: Preparing For External Storage Xp Operations

    Web Console For instructions on installing and using Command View XP or XP Remote Web Console, see the HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200.
  • Page 16 In External Storage XP panes, the array appears as “256”. • Alternate paths are in Multi mode. HP StorageWorks 200 Storage Virtualization System • In External Storage XP panes, the array appears as “SVS200”. Alternate paths are in Multi mode.
  • Page 17 Table 2 Storage arrays that can be connected as external arrays (continued) Storage array Notes Lightning 9900V series subsystem • “Lightning 99xxV series subsystem” indicates the Lightning 9970V and Lightning 9980V. • In this user guide, the arrays appear as “Lightning 9900V subsystem”.
  • Page 18 “256”. • Alternate paths are in Multi mode. IBM Storage Subsystem For specific supported storage arrays, contact your HP account support representative. EMC Storage Subsystem For specific supported storage arrays, contact your HP account support representative. Fujitsu Storage Subsystem For specific supported storage arrays, contact your HP account support representative.

  • Page 19: External Storage Xp Requirements

    Enable the External Storage XP options in Command View XP or XP Remote Web Console and on each External Storage XP array. For instructions, see the HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200.

  • Page 20: External Ports

    • Ports that can be set to external ports (see ”External ports” on page 20) • External array and LUs to map to the internal LDEVs (see”External LU to be mapped” on page 20) • Configuration of external LU groups (see ”External LU groups”...
  • Page 21 If you use an external LU and set Cache Mode to Disable for Cache LUN XP operations, you cannot use the Cache LUN XP Bind mode. For more information, see the HP StorageWorks Cache LUN XP user guide for XP12000/XP10000/SVS200.

  • Page 22: Alternate Paths

    (SLPR) the CLPR belongs to. For more information about CLPRs and SLPRs, see the HP StorageWorks XP Disk/Cache Partition user guide. Alternate paths When mapping an external LU as an internal LDEV, paths are set from the internal LDEV to the external If two or more paths to the external LU are equipped from different clusters, the number of paths you set when mapping the volume are available.

  • Page 23: Examples Of Switching I/O Execution Paths To Alternate Paths

    Since two ports of different clusters must be set in the local array for External Storage XP to use alternate path settings, HP does not recommend the configuration shown in Figure...

  • Page 24: Alternate Path Mode Is Multi Mode

    For more information about path status, see ”Adding alternate paths by selecting multiple external LUs (Add Paths)” on page 89. • Alternate path mode is Multi mode Figure 5 shows an example of when the alternate path mode is Multi mode. When an error occurs in one path, I/Os execute using paths other than the error path.

  • Page 25: Alternate Path Mode Is Single Mode

    NOTE: As you restore the path with a priority higher than the current path, the I/O execution path automatically switches to the restored path with the highest priority. Figure 6 Alternate path mode is Single mode • Alternate path mode is Single mode and at least one alternate path is in Standby status Figure 7 shows an example of when the alternate path mode is Single mode and there are alternate paths in Normal and Standby status.

  • Page 26: Alternate Path Mode Is Single Mode With Alternate Paths In Normal And Standby

    NOTE: When the external array is an EVA array, as you restore the path with the highest priority, the I/O execution path switches back to the restored highest priority path. In this case, the status of the path for which the status changed to Normal when the error occurred changes back to Standby.

  • Page 27: Powering Arrays On Or Off

    Figure 8 Alternate path mode is Single mode with alternate paths in Standby only NOTE: External arrays with Active/Standby (A/S) controllers, such as the MSA, are an example of Figure 8. A notable characteristic of using A/S controller arrays as external storage is that there is typically only a single port to the owning controller.

  • Page 28: Powering Local Arrays On Or Off

    This command checks if defined information about the mapped external LU and the actual external LU status match. If the external LU can be used as the mapped local array volume, the external LU is set to accept I/O, and you can continue using the external LU as a mapped LU. Use this command to restore the external LU, which is set to reject host I/O operations by the Disconnect Subsystem or Disconnect Volume command, as the mapped volume.

  • Page 29: Powering External Arrays On Or Off

    ”Mapping external LUs (Add LU)” on page 70. For open-system emulation types (such as OPEN-V, which HP recommends), the status of the mapped LDEV is set to Normal and is not automatically formatted. To optimally initialize the mapped LU’s data...

  • Page 30: Using Existing Data In Mapped External Lus

    Volume Manager to format the mapped LU. For instructions, see the HP StorageWorks LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200. To to step 4. For mainframe-system emulation types (for example, 3390-XX), the status of the mapped LU is set to Blockade, pending resizing and formatting.

  • Page 31: Uninstalling External Storage Xp

    For the local array, use the Command View XP or XP Remote Web Console Licensing module to remove the External Storage XP license key. For instructions, see the HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200.

  • Page 32: Limitations On External Storage Xp Operations

    Continuous Access XP P-VOLs, S-VOLs, and journal volumes are not supported on MSA arrays. • HP does not recommend that volumes involved with Snapshot XP reside on external MSA arrays. • If you map an external LU that is more than 2 TB with the setting of OPEN-V emulation type, you can access data stored in the field up to 2 TB.

  • Page 33: External Lu Capacity Is Smaller Than The Specified Emulation Type's Basic Capacity

    Available capacity decreases by the size of the XP array management information area, and all prior data must be considered lost. For more information, see the HP StorageWorks Flex Copy XP user guide. Figure 12 shows an example where the external LU’s original capacity is larger than (or a multiple of) the normal size of the local array’s emulation type (OPEN-3 in this example).
  • Page 34 • If you mapped a volume that has not been zero-formatted on the external array side, format the volume on the local array side. For instructions on the formatting and Write to Control Blocks operations, see the HP StorageWorks LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200.

  • Page 35: When External Lu's Emulation Type Is Open

    • You can delete up to 256 mappings for external LUs at one time. • Operations cannot be performed if some parts of the local array are blocked. In this case, restore blocked parts of the local array, and retry the operation. •...

  • Page 36: When External Lu's Emulation Type Is For Mainframes

    LUs, consider the external array’s I/O capacity. • When executing commands in HP StorageWorks software products to the mapped external LU and, therefore, too many I/Os are issued for the external array to process, commands might time out and errors might occur.

  • Page 37: Combining External Storage Xp With Other Hp Storageworks Products

    Combining External Storage XP with other HP StorageWorks products You can use HP StorageWorks software products to operate and manage the external LUs you set using External Storage XP. The following sections provide configuration examples for specific HP StorageWorks software products: •...

  • Page 38: Using External Lus For Auto Lun Xp Operations

    LU is mapped through that external port, the topology setting is not available. NOTE: Some mainframe products might be marketed under different HP names and are not supported at this time. Contact your HP account support representative for the latest support matrix.

  • Page 39: Using External Lus For Continuous Access Xp Operations

    LU. Only OPEN-V emulation can be used to read existing data in the external LU from the local array side. To copy existing data in the mapped external LU using HP StorageWorks software products, such as Continuous Access XP and Business Copy XP, the mapped external LU’s emulation type must also be OPEN-V.

  • Page 40: Using External Lus For Continuous Access Xp Journal Operations

    Continuous Access XP operations, see the HP StorageWorks Continuous Access XP user guide for the XP12000/XP10000/SVS200. Figure 15 Example of Continuous Access XP operations Use External Storage XP to map a volume in the external array to an internal LDEV of the local Continuous Access XP RCU array.

  • Page 41: Using External Lus For Business Copy Xp Operations

    Normal. However, the volume-formatting process is not automatically executed. To optionally format the mapped volume, use the Custom Volume Size (CVS) function. For instructions, see the HP StorageWorks LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200.

  • Page 42: Example Of Business Copy Operations

    Business Copy XP pair’s P-VOL. For more information, see the HP StorageWorks Business Copy XP user guide for the XP12000/XP10000/SVS200. Figure 17 Example of Business Copy operations Use External Storage XP to map a volume in the external array to an internal LDEV of the local array.

  • Page 43: Managing Cache With External Storage

    Determining, setting, or changing the external LU cache mode You set the cache mode when you define external LUs. HP strongly recommends that you set cache mode to Disabled for external LUs. For instructions on mapping external LUs in a new configuration, see ”Mapping external LUs (Add...

  • Page 44: Determining If The Cache Mode Is Disabled

    Determining if the cache mode is disabled If you have an existing configuration and need to determine if your external LUs are configured with cache mode disabled, follow this procedure: In the XP Remote Web Console main pane, click the External Storage button in the left pane. The LU Operation pane appears.

  • Page 45: Lu Operation Pane, Lu Number And Uuid

    In the XP Remote Web Console main pane, click the External Storage button in the left pane. The LU Operation pane appears. To find the LU number and UUID, select an external device group in the Device tree (Figure 19). The LU number appears in the LUN column in the Device list.

  • Page 46: Deleting And Remapping The External Lu

    The Path Setting pane appears (Figure 21). Figure 21 Path Setting pane To find the CVS settings, mapped location, external group number, and CU:LDEV identifier, right-click the LDEV in the Device list on the LU Operation pane, and select LDEV Information (Figure 20).

  • Page 47: Partitioning Cache For External Storage

    NOTE: All HP 200 Storage Virtualization System volumes are external. Partition SVS200 cache according to the other recommendations made in this section. •...

  • Page 48: Determining The Number And Size Of Needed Partitions

    Ensure the XP Disk/Cache Partition license is installed, you have Administrator authority on the array, and you are in Modify mode in XP Remote Web Console. For more information about license keys and user administration procedures, see the HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200.

  • Page 49: Partition Definition Pane

    Select the new CLPR in the tree, and change the size and other CLPR settings as needed (Figure 23). Figure 23 Partition Definition pane Click Apply for the changes to becomes effective. Repeat step 3 through step 5 to define any additional CLPRs that you need. To allocate external storage groups to a CLPR: a.

  • Page 50: Partition Definition Pane, Cut Option

    c. Select and right-click the external storage groups that you want to assign to another CLPR, and then select Cut (Figure 24). Figure 24 Partition Definition pane, Cut option d. Right-click the CLPR that you want to assign the selected external storage groups to, and then select Paste Parity Group (Figure 25).

  • Page 51: Changing Storage System Modes

    HP service representatives can set the XP and SVS200 array system modes to adjust the array’s behavior. For SVS200 arrays, no adjustments are needed. For XP arrays, contact your HP account support representative to change the system modes if either of the following is true: •...
  • Page 52 Managing cache with external storage...

  • Page 53: External Storage Xp Panes

    External Storage XP panes External Storage XP operations involve the LU Operation and Port Operation panes. In addition to these two panes, the Flex Copy pane is available if you licensed Flex Copy XP. When you select a tab, the corresponding pane appears.

  • Page 54: Lu Operation Pane

    LU Operation pane This pane appears when you start External Storage XP. Information about the external array appears on the LU Operation pane. Use this pane to perform operations such as mapping external LUs and setting alternate paths. Device tree Device list Filter button Information area...

  • Page 55: Device Tree

    • Total number of Devices: Number of external LUs that are connected. • Total number of External Groups: Number of external LU groups that are set. • Total number of External LUs: Number of external LUs that are connected. • Found WWNs: WWNs found when you clicked Discovery in the Device tree. •...

  • Page 56: Device List

    Displays the name of the external array that can be connected using External Storage XP in the tree under External Devices. When you select an external array’s product name, the Device list displays detailed product information. • External LU group number Displays user-assigned numbers in the branch under the external array’s product name, which is connected to the local array and is already used.

  • Page 57: Mapped External Lu Status Values

    Table 8 External array status values (continued) LU status Description Warning FC path or paths have an abnormal status. Check the status of the paths. Checking External Storage XP is verifying configuration information defined for FC paths. Cache Destage External Storage XP is writing all data in the local array cache memory to the LU. Disconnect Connection to external array or external LU was intentionally stopped using the Disconnect Subsystem or Disconnect Volume command.

  • Page 58: Wwn Tree

    • Ex-Dev. Status: Status of the operation executed to the external array, or status of the path connection. Possible values: Normal, Unknown, Blockade, Warning, Checking, Cache Destage, and Disconnect. For a description of these values, see Table • LDEV Status: Mapped external LU’s status. Possible values: Normal, Unknown, Blockade, Warning, and Format.

  • Page 59: Wwn List

    WWN list Displays information about the connection status of the local array and external array corresponding to the item selected in the WWN tree. You can sort the list by displayed items. For example, to sort by the LUN number, select LUN on the list. When performing setting operations, the settings appear in the Preset list and the corresponding row in the WWN list appears in blue italics.
  • Page 60 • Blockade: Path is blocked. • Disconnect: Connection to the external array or external LU was intentionally stopped using the Disconnect Subsystem or Disconnect Volume command. • Warning: There are paths whose status is not normal. Check the status of the paths. •...

  • Page 61: Port Tree

    • Characteristic2: External LU’s extended identifying information. This information is used for identifying logical volumes in the EVA array. For more information, see ”Identifying logical volumes of EVA arrays (using Characteristic 2)” on page 124. Port tree When you select the Port tab, this tree displays information about ports that have the External attribute. The contents displayed in the Port list changes depending on the item selected in the Port tree.
  • Page 62 • Margin: Additional wait time (in seconds) to FLI_TOV (FLOGI wait time) or PLI_TOV (PLOGI wait time). External Storage XP automatically sets this value. You cannot change the value. As a result, the sum of the FLI_TOV time and margin time, or the sum of the PLI_TOV time and margin time is set as a total wait time.

  • Page 63: Filter Button

    alternate path that is in the Standby status. When the primary path changes, the status of the path becomes Normal. • Backoff: External array replied Backoff. The path status is waiting for recovery because a temporary error occurred in the external array’s volume. Even if the primary path’s status becomes Backoff, the primary path does not changed to the alternate path immediately.

  • Page 64: Port Operation Pane

    Displays the Preset Detail window with detailed information about settings selected in the Preset list. When an error code appears in the Preset list, a corresponding error message appears in this window. Figure 35 Preset Detail window (mapping operation) • Delete Cancels settings selected in the Preset list.

  • Page 65: Port Operation Tree

    Displays information about the selected port in the Port list (right pane). You can select Subsystem, a port attribute, or a port number. For more information, see ”Port Operation tree” on page 65. • Port Operation list Displays detailed information about ports selected in the Port Operation tree. For more information, ”Port Operation list”...

  • Page 66: Port Operation List

    When selected, displays ports designated as host target ports (used for host connect). • RCU Target When selected, displays ports designated as an RCU target (receiving) port (used for Continuous Access XP, TrueCopy for z/OS, Continuous Access XP Journal, Universal Replicator for z/OS, and so on).

  • Page 67: Preset Detail Window (Changing Port Attribute)

    Displays the Preset Detail window with detailed information about actions selected in the Preset list. When an error code appears in the Preset list, a corresponding error message appears in the Preset Detail window. Figure 39 Preset Detail window (changing port attribute) •...
  • Page 68 External Storage XP panes...

  • Page 69: Configuring External Lus

    113. Start External Storage XP operations. For instructions, see the HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200. Set the external array port attribute to External. For instructions, see ”Setting a local array’s port...

  • Page 70: Setting An External Array's Port

    If you select a mainframe emulation type on the Add LU pane, use Volume Manager to reformat the volume or perform the Write to Control Blocks operation. For instructions, (see the HP StorageWorks LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200.

  • Page 71: Mapping External Lus Individually (Add Lu)

    Mapping external LUs individually (Add LU) This section describes mapping operations starting with the Add LU command. Use the Add LU (Figure 41), Select Paths (Figure 42), SSID (Figure 45), and Set SSID (Figure 46) panes for mapping external LUs individually.
  • Page 72 External LU’s identification number. • Characteristic2 External LU’s extended identifying information. This information is used for identifying logical volumes in the EVA array. For more information, see ”Identifying logical volumes of EVA arrays (using Characteristic 2)” on page 124. • ExG (1-16384) Group number of the connected external LUs.
  • Page 73 ”External LU attributes set by mapping” on page 20). HP recommends that you set cache mode to Disable. NOTE: • If you set the IO Suppression mode to Enable, Cache Mode becomes Disable. • If you select Disable, Cache LUN XP’s bind mode cannot be set.

  • Page 74: Select Paths Pane

    Displays the XP12000/XP10000/SVS200 CU:LDEV numbers of external LUs mapped as internal LDEVs. (N/A) (Not Assigned) means the external LUs are not yet mapped as internal LDEVs. To map an external LU as an internal LDEV, select an external LU with (N/A) in the CU:LDEV list. To map all external LUs in the CU:LDEV list at one time, use the Linear button.
  • Page 75 • Unselected Paths Ports excluded from being candidates for the ports setting the primary and alternate paths appear among the external array ports that can be set as the primary and alternate paths. WWNs identifying the external array ports appear in the list. •...

  • Page 76: Add Lu Pane

    following the internal LDEV you selected (Figure 43). The LDEV numbers of the selected XP LDEV are in a series. When Interval is set, the mapping is done at the specified interval. Figure 43 Add LU pane (mapping using the Linear button) •...

  • Page 77: Ssid Window

    • If you need to set the SSID, the SSID window appears. Go to step Figure 45 SSID window • If the SSID setting is not necessary, the Add LU window closes, and the LU Operation pane appears. Settings appear in blue italics in the Device tree and Device list. Contents specified in the Add LU window appear in the Preset list.

  • Page 78: Mapping Multiple External Lus At One Time (Add Lu (Auto))

    Mapping multiple external LUs at one time (Add LU (Auto)) This section describes the procedure to map multiple external LUs at one time. The procedure starts with the Add LU (AUTO) command. NOTE: Before mapping the external LU, you must check whether any application (for example, RAID Manager XP) using the command device is in progress.
  • Page 79 If you plan to use the mapped external LU for a Flex Copy XP pair, you must specify OPEN-V. When the external LU to be mapped has the VMA setting, you must select OPEN-V. Due to the advantages of the OPEN-V emulation type, HP recommends OPEN-V as the default type for use with External Storage XP.
  • Page 80 To have External Storage XP select the first CU:LDEV number for the mapped internal LDEV, leave the default (“- : -”). External Storage XP searches for an available CU:LDEV number starting with 00:00, and selects the first one it finds. To specify the first CU:LDEV number and interval, click Select LDEV.

  • Page 81: Select Ldev Window

    Select LDEV window Figure 48 Select LDEV window • CU list CU number of the local array to which you want to map the external LU. • Interval Interval of the CU:LDEV number for mapping each volume. When two or more LDEVs are created from one external LU and mapped, the CU:LDEV number is set at intervals specified in each created LDEV.
  • Page 82 In the Device tree, select the port (WWN) you want to connect from the WWNs displayed. External LUs that can be connected from the port (WWN) selected in the tree appear in the Device list. In the Device list, select the external LUs you want to map as internal LDEVs, right-click, and select Add LU (Auto).

  • Page 83: Displaying Detailed Information Stored In Vma (Vma Information)

    49). To view the VMA Information pane, select WWN in the Device tree, and select the external array’s port. Right-click the volume you want to display, and select VMA Information. For more information about items displayed in the VMA Information pane, see the HP StorageWorks LUN Security XP Extension user guide.

  • Page 84: Setting Alternate Paths For External Lus

    • Mode Mode the RAID Manager XP user assigns to the logical volume. • Zer: Zero Read Cap mode is assigned to the logical volume. • Inv: Invisible mode is assigned to the logical volume. • Zer/Inv: Zero Read Cap and Invisible mode are assigned to the logical volume. •...

  • Page 85: Path Setting Window

    The Path Setting window displays information about external arrays and the condition of paths set from the internal LDEV to the external LU. Defined paths Available paths Figure 50 Path Setting window • Vendor External array’s vendor. • Product External array’s product name. •...
  • Page 86 • Normal: Path is normal. • Unknown: Path status is unknown. • Blockade: Path is blocked. • External device setting changed: External array’s setting changed. For example, the path definition was deleted or the external array itself was replaced. • LDEV size reduced: External array’s volume capacity setting changed (volume capacity was reduced).

  • Page 87: Defining Alternate Paths

    • OK button Closes the Path Setting window, and returns to the LU Operation pane. Contents specified in the Path Setting window appear in blue italics in the Device list, and settings appear in the Preset list. • Cancel button Cancels all alternate path setting operations, closes the Path Setting window, and returns to the LU Operation pane.

  • Page 88: Canceling Alternate Path Definitions

    Detailed information about the currently used path and alternate path appears in the Configured Paths table, and paths that can be defined as alternate paths appear in the Available Paths table. In the Configured Paths table, right-click the row of the path defined as the alternate path, and select Priority Up (Figure 51).

  • Page 89: Adding Alternate Paths By Selecting Multiple External Lus (Add Paths)

    Follow step 1 step 3 ”Defining alternate paths” on page 87. In the Configured Paths table, right-click the row of the path currently defined as the alternate path, and select Delete. The selected alternate path’s definition is canceled, and detailed information about the path is deleted from the Configured Paths table.

  • Page 90: Deleting Alternate Paths By Selecting Multiple External Lus (Delete Paths)

    • Release Moves WWNs selected in Selected Paths to Unselected Paths. • Saves settings in the Add Paths window, closes the Add Paths window, and displays the Path Setting window. • Cancel Cancels all settings in the Add Paths window, and closes the window. To add alternate paths to multiple external LUs at one time: Select the LU Operation tab.

  • Page 91: Delete Paths Window

    NOTE: Use the Delete Paths window to delete paths to multiple external LUs at one time. However, the deleted path settings might not be applied because of the current path setting of each volume. After you set the deletion in the Delete Paths window, check whether or not the new path settings can be applied in the Path Setting window for each external LU.

  • Page 92: Checking An External Lu's Status (Ldev Information)

    Checking an external LU’s status (LDEV Information) After mapping an external LU as a local array internal LDEV, the external LU is available for operations in External Storage XP, Flex Copy, and other HP StorageWorks products that support mapped external LUs. Use the LDEV Information window (Figure 54) to check the status of mapped external LUs.

  • Page 93: Restoring External Lus (Restore)

    External LU’s identification number. • Device External LU’s device name. • Capacity External LU’s capacity. When the mapped external LU’s emulation type is for open systems, capacity is displayed in 512-byte blocks. When the mapped external LU’s emulation type is for mainframe systems, capacity is displayed in cylinders.

  • Page 94: Displaying Configuration Information For External Lus (Volume Detail)

    NOTE: If you set a mainframe-system emulation type (such as 3390-3) when you mapped the external LU, and you restore the mapped LU without formatting the LU or performing the Write to Control Blocks operation, data in the volume cannot be read correctly. Select the LU Operation tab.

  • Page 95: Disconnecting External Arrays Or Lus

    volume in the LDEV list, the Volume Detail window displays a list of all LDEVs that make up the LUSE volume. Figure 56 Volume Detail window You can also check the LDEVs making up a LUSE volume by selecting View all Volumes at the bottom of the LDEV Information window.

  • Page 96: Disconnecting All External Lus In An External Array (Disconnect Subsystem)

    • When executing the Disconnect Subsystem or Disconnect Volume command, the Ex-Dev. Status column in the Device list changes to Cache Destage. Even if there is no data left in cache memory, the displayed status remains as Cache Destage, until the Disconnect Subsystem or Disconnect Volume command processing is complete.

  • Page 97: Checking The Connection Status And Resuming External Lu Operations (Check Paths & Restore Vol.)

    In the Device list, right-click the external LU you want to disconnect from the local array, and select Disconnect Volume. The selected external LU group number in the Device tree and the selected external LU in the Device list appear in blue italics. It also appears in the Preset list. To check details of the intended operation, right-click the row in the Preset list, and select Detail.

  • Page 98: Restoring External Lus Individually (Check Paths & Restore Vol.)

    The path status in the Path Setting pane changes to Checking. When External Storage XP finishes checking path status and the external array can be restored, the Status column changes to Normal. If the external array cannot be restored, the status changes to Blockade. Restoring external LUs individually (Check Paths &...

  • Page 99: Stopping The Use Of Paths To An External Lu By Specifying An External Array's Wwn (Disconnect Paths)

    In the Device list, right-click the external LU you want to restore, and select LDEV Restore. The selected external LU group number and external LU appear in blue italics in the Device tree and Device list. The contents of the setting appears in the Preset list. To check setting details, right-click the setting in the Preset list, and select Detail.

  • Page 100: Changing An External Array's Port Setting

    • If you selected the product name of the connected external array in the WWN tree, select the WWN identifying the external array’s port in the WWN list. In this case, you can restore the path of all ports of the local array connected to the WWN at one time. •...

  • Page 101: Stopping The Use Of Paths To An External Lu By Specifying A Local Array's Port (Disconnect Paths)

    Click OK. The Change Parameter pane closes, and the LU Operation pane appears. Selected items appear in blue italics in the WWN tree and WWN list. The contents of the setting appears in the Preset list. To check the setting details, right-click the setting in the Preset list, and select Detail. To cancel the setting, right-click the setting in the Preset list, and select Delete.
  • Page 102 Before deleting the external LU mapping, notice if any of the following are true: • Whether or not the execution of any application (for example, RAID Manager XP) that is using the command device is in progress. If any application using an external LU command device is executing, stop the application. •...

  • Page 103: Remote Command Devices

    Business Copy XP or Continuous Access XP pairs in the external array. For more information about RAID Manager XP and command devices, see the HP StorageWorks RAID Manager XP User’s Guide.

  • Page 104: Information Displayed In The Device Column For Remote Command Devices

    Device list XP12000 Disk Array Format: “Emulation Type” + “-CM” XP10000 Disk Array Example: OPEN-V-CM, OPEN-3-CM HP 200 Storage Virtualization System XP1024/XP128 Disk Array TagmaStore™ Universal Storage Platform subsystem TagmaStore™ Network Storage Controller subsystem Lightning 9900V series subsystem SANRISE Universal Storage Platform subsystem...

  • Page 105: Mapping Command Devices As Remote Command Devices

    • Device name NOTE: The device name reported to the host is the same as the one displayed in the Device column of the Device list. For the device names reported to the host, see Table • The following are restrictions for mapping command devices as remote command devices. Table 11 Restrictions on remote command devices Item...
  • Page 106 106 Remote command devices...

  • Page 107: Troubleshooting External Storage Xp

    If you have a problem with the Command View XP computer or Command View XP or XP Remote Web Console software, see the HP StorageWorks Command View XP user guide for XP Disk Arrays or the HP StorageWorks XP Remote Web Console for XP12000/XP10000/SVS200 for troubleshooting information.
  • Page 108 Corrective action: The port of the external array is recognized. Check the external array’s setting and the condition of the connection to the external array (for example, cables or switches). If you cannot restore the path, contact your HP account support representative. 108 Troubleshooting External Storage XP...
  • Page 109 (for example, check whether the configuration assigns too much load on the external array). If you cannot restore the path, contact your HP account support representative. LDEV reserved Status: The external array’s status is Reserved. You cannot access the external array’s device from the...
  • Page 110 Corrective action: Check the condition of the connection to the external array. If you cannot restore the path, contact your HP account support representative. Status: Internal error A program error occurred, or there is a logical contradiction.
  • Page 111 Check Paths & Restore Vol. than 10 minutes, but the command again. device’s status does not If the problem persists despite retrying, contact your HP account support change from Checking. representative. The Disconnect Subsystem or...
  • Page 112 Table 12 General External Storage XP troubleshooting (continued) Error Corrective action The message The device status is currently changing. Please wait for a while, and then check the device status again. When the transition of the device status completes INTERVENTION REQUIRED is issued to the mainframe normally, the device can be used immediately.

  • Page 113: A Notes On Connecting External Arrays

    Notes on connecting external arrays NOTE: If you have an EVA or MSA connected as external storage and you need to perform a firmware upgrade on the EVA or MSA, you must use the EVA/MSA offline firmware upgrade function. When the EVA or MSA is connected as XP external storage, online EVA/MSA firmware upgrade is not supported at this time.
  • Page 114 Table 13 System parameter settings (Thunder 9500V subsystems) (continued) Pane name Parameter Parameter setting Common 1 Delay Planned Shutdown You can either specify this parameter or omit specifying this parameter. OPTION 1 SCSI Fibre Channel Common Options You can either specify this parameter or omit specifying this parameter.

  • Page 115: Relationship Between Serial Numbers In The Device List On The Lu Operation Pane And Thunder 9500V Subsystem Models

    Relationship between serial numbers in the Device list on the LU Operation pane and Thunder 9500V subsystem models When the external array is a Thunder 9500V subsystem, you can identify the subsystem model from the serial number displayed in the Serial column in the Device list on the LU Operation pane. Table 14 shows the relationship between serial numbers displayed in the Serial column and subsystem models.

  • Page 116: Path Status And Examples Of Recovery Procedures (Thunder 9500V Subsystems)

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact you HP account support representative. Table 16 Path status and examples of recovery procedures (Thunder 9500V subsystems)

  • Page 117: Connecting Tagmastore Ams And Tagmastore Wms Subsystems

    Connecting TagmaStore AMS and TagmaStore WMS subsystems System parameters for connecting TagmaStore AMS and TagmaStore WMS subsystems Table 17 explains whether to specify system parameters when making settings for ports on TagmaStore AMS and TagmaStore WMS subsystems. Table 17 System parameter settings (TagmaStore AMS and TagmaStore WMS subsystems) Pane name Parameters Parameter setting...

  • Page 118: Relationship Between Serial Numbers In The Device List On The Lu Operation Pane And Tagmastore Ams And Tagmastore Wms Subsystem Models

    Relationship between serial numbers in the Device list on the LU Operation pane and TagmaStore AMS and TagmaStore WMS subsystem models When the external array is a TagmaStore AMS or TagmaStore WMS subsystem, you can identify the subsystem model from the serial number displayed in the Serial column in the Device list on the LU Operation pane.

  • Page 119: Path Status And Examples Of Recovery Procedures (Tagmastore Ams And Tagmastore Wms Subsystems)

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact your HP account support representative. Table 20 Path status and examples of recovery procedures (TagmaStore AMS and TagmaStore WMS...

  • Page 120: Connecting Xp12000/Xp10000 Disk Arrays

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact your HP account support representative. Table 21 Path status and examples of recovery procedures (XP12000/XP10000 Disk Arrays)

  • Page 121: Connecting Xp1024/Xp128 Disk Arrays

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact your HP account support representative. Table 22 Path status and examples of recovery procedures (XP1024/XP128 Disk Arrays)

  • Page 122: Connecting Xp512/Xp48 Disk Arrays

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact your HP account support representative. Table 23 Path status and examples of recovery procedures (XP512/XP48 Disk Arrays)

  • Page 123: Connecting Hp 200 Storage Virtualization System As External Storage

    Connecting HP 200 Storage Virtualization System as external storage When connecting an HP 200 Storage Virtualization System (SVS200) as the external array, you must set the SVS200 port to a host group for Windows hosts (host mode 0C: Windows or host mode 2C: Windows Extension).

  • Page 124: Path Status And Examples Of Recovery Procedures (Svs200)

    ”Troubleshooting External Storage XP” on page 107 and this table to recover the path status. If you cannot restore the path, contact your HP account support representative. Table 24 Path status and examples of recovery procedures (SVS200)

  • Page 125: Alternate Path's Behavior When An Eva Array Is Connected

    If you search for logical volumes by specifying the WWN that indicates EVA Port A in the configuration, such as in Figure 60, logical volumes named LUN 1 and LUN 2 are found for both HostGroup-1 and HostGroup-2. In this case, two different logical volumes with the same name, such as LUN 1 and LUN 2, are found as logical volumes that can be connected from EVA Port A, but you can only tell which LUN 1 and LUN 2 belong to HostGroup-1 or HostGroup-2 by examining the Characteristic field.
  • Page 126 126 Notes on connecting external arrays...

  • Page 127: B Required Volume Capacity For Emulation Types

    Required volume capacity for emulation types When mapping an external LU as a local array internal LDEV, you must specify the mapped volume’s emulation type. The capacity required for the LDEV to be mapped is the total capacity of the data area for storing actual user data and the control information area for storing control information.

  • Page 128: Ldev Capacity

    Figure 61 shows the relationship of the minimum LDEV capacity, base LDEV capacity, minimum data area capacity, base data area capacity, and control information area capacity. Figure 61 LDEV capacity Figure 62 shows how to determine the volume capacity using the example of the OPEN-3 case. Figure 62 Calculating LU capacity (OPEN-3 example) Table 26...
  • Page 129 Table 26 LDEV capacity information for each emulation type (continued) Emulation type Minimum data area Base data area Control information capacity (blocks) capacity (blocks) area capacity (blocks) 3380-KA 72,000 3,823,200 10,080 3380-KB 72,000 3,823,200 10,080 3380-KC 72,000 3,823,200 10,080 3390-3 87,000 5,809,860 10,440...

  • Page 130: Volume Capacity Information For Each Emulation Type

    Table 27 Volume capacity information for each emulation type Emulation type Base LDEV Minimum LDEV Maximum capacity Maximum number capacity (blocks) capacity (blocks) of external LU of LDEVs when (blocks) maximum capacity of external LU is mapped 3380-3 4,818,240 82,080 1,207,934,976 3380-3A 4,818,240...

  • Page 131: C Adjusting Volume Capacity For Copy Pair Setting

    CV with the same capacity as the mapped internal LDEV (B) out of the local array volume (C) using Volume Manager. For more information, see the HP StorageWorks LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200.

  • Page 132: Copying Data To External Arrays (Setting External Lus As S-Vols)

    Map the external LU (A) as an internal LDEV (B) of the local array. Set the emulation type to the same as the copy source volume (C). Check the capacity of the internal LDEV (B) to which the external LU (A) is mapped. If the mapped internal LDEV’s (B) capacity is not same as the copy source volume (C), use Volume Manager to create a CV with the same capacity as the copy source volume (C) out of volume (B).

  • Page 133: D Using An Xp12000/Xp10000/Svs200 With An Eva3000/5000 External Storage

    EVA in addition to the XP12000/XP10000/SVS200. This also allows for connecting hosts to the EVA that run software applications such as HP StorageWorks Command View EVA and System Insight Manager so the EVA can be managed in-band as well as monitoring its operational status. The XP12000/XP10000/SVS200 does not forward detailed SIM (status) messages the EVA generates during operation.

  • Page 134: Expanded Configuration

    For the XP12000/XP10000/SVS200 to use LUs resident on the attached EVA, a host object must be defined for the XP12000/XP10000/SVS200. Use HP StorageWorks Command View EVA to create EVA host objects. Set Host name to a unique name representing the XP12000/XP10000/SVS200, and set Port WW Name to the world wide port name of a...

  • Page 135: Creating And Presenting Eva Vdisks

    connected XP12000/XP10000/SVS200 external port. Additionally, set Host OS to Microsoft Windows for the XP12000/XP10000/SVS200 to use the EVA LUs correctly. Figure 67 illustrates this step. Figure 67 Creating EVA host objects After the host object is created, add the remaining XP12000/XP10000/SVS200 external ports by selecting the new host object, and clicking the Ports tab.

  • Page 136: Defining Xp12000/Xp10000/Svs200 External Ports

    HP recommends defining Vdisk settings so the number of Vdisks presented to the XP is balanced between the two EVA controllers and across controller ports. Figure 69 Selecting Vdisk’s Preferred path/mode After EVA Vdisks are created, they can be assigned to the previously defined XP12000/XP10000/SVS200 host object;...

  • Page 137: Defining Xp12000/Xp10000/Svs200 External Storage Ldevs

    XP12000/XP10000/SVS200 ports to external ports. On the Port Operation pane in External Storage, right-click on the desired ports, and select Change to External. Figure 71 illustrates this step. Figure 71 Defining XP12000/XP10000/SVS200 external ports After external ports are defined, EVA LUs presented to the XP12000/XP10000/SVS200 can be defined as XP external storage LDEVs.

  • Page 138: Selecting Eva Lus

    NOTE: You must select external storage LUs through the presenting controller. Failure to do so results in new external LDEVs being placed in a blockade state shortly after a host attempts to access them. Figure 72 Selecting EVA LUs After you select an external logical unit (LU), the Add LU pane appears. At this point, you can configure each individual external LU by choosing options such as the emulation type, the number of LDEVs (CVS is used), and the LU’s unique LDEV identifiers within the XP12000/XP10000/SVS200.

  • Page 139: Recommendations

    EVA3000/5000 models have two ports per controller) than a similar configuration with an MSA (only one port per controller). In spite of this, HP strongly cautions you to carefully weigh the financial cost of a dedicated XP12000/XP10000/SVS200 external port versus the benefit of any added EVA external storage performance.

  • Page 140: Troubleshooting

    Troubleshooting • Be careful to define an external storage LDEV presented to the XP12000/XP10000/SVS200 by the EVA from the EVA controller that is presently serving its associated LU in an active status. • If you attempt to define an LDEV from an LU via that LU’s passive controller, the resulting external storage LDEV is placed in a blockade state.

  • Page 141: E Configuring Msa1000/1500 As External Arrays

    Use Selective Storage Presentation to configure the MSA LUs involved with External Storage XP. Connecting MSA1000/1500 If you connect an HP StorageWorks Modular Smart Array (MSA) with two controllers (highly recommended) as an external array, set the port’s host mode to Tru64 and use Selective Storage Presentation.

  • Page 142: Setting Up The Msa

    LUN security on the MSA using the ACU Selective Storage Presentation (SSP) functionality. Use the HP StorageWorks Array Configuration Utility (ACU) to configure the MSA for its role as an external array. ACU runs from a server attached to the MSA via a Fibre Channel path.

  • Page 143: Selective Storage Presentation

    presentation to the XP12000/XP10000/SVS200. For example, suppose you want to create a 40 GB (40960 MB) LU on the MSA for use as XP12000/XP10000/SVS200 external storage. If you request only the exact size needed, the ACU optimizes the LU to a size of 40959 MB, which is 1 MB smaller than needed.
  • Page 144 144 Configuring MSA1000/1500 as external arrays...

  • Page 145: Index

    Index Cache Mode Auto Map window Active/Standby (A/S) controllers LU window ACU (Array Configuration Utility) remote command devices ACU Selective Storage Presentation (SSP) restrictions Add LU (Auto) operation settings Add LU operation cache, managing Add LU window capacity, required alternate paths Check Paths &...
  • Page 146 Disconnect Volume command external arrays disconnecting external LUs powering arrays on and off restrictions Add LU window troubleshooting compatible storage devices Discovery operation, troubleshooting configuring document connection status conventions copying data from feedback copying data to prerequisites defined related documentation Device List Device list Device tree...
  • Page 147 Subscriber’s choice web site alternate paths, defining technical support alternate paths, deleting to multiple HP StorageWorks XP Tiered Storage Manager Business Copy XP operations capacities configuring I/O execution paths, switching to alternate paths connection status...
  • Page 148 platforms supported Port Operation list managing cache Port Operation pane manuals Port Operation tree mapping ports access restrictions alternate paths Add LU command Device tree Add LU window external array settings all external LUs at once limitations alternate paths, defining list of attributes local array settings...
  • Page 149 XP12000/XP10000 arrays XP512/XP48 arrays web sites stopping external LU paths HP documentation storage platforms supported HP storage Subscriber’s choice, HP HP Subscriber’s choice support, technical support supported storage platforms and firmware writing data to mapped external LUs S-VOLs WWN List...
