- Page 1 User Manual Series...
-
Page 2: Table Of Contents
Table of Contents Getting to know the recorder ......................2 Power key ............................3 LED indicators ..........................3 Using the touch screen ......................4 Inserting a memory card ......................... 5 Using your recorder in a vehicle ....................6 Connecting to external devices .....................8 Connecting to your computer ....................8 Connecting to a High Definition (HD) device ...............8 Operating basics ..........................9 Turning the recorder ON and OFF ..................9... -
Page 3: Getting To Know The Recorder
Getting to know the recorder NOTE: The screenshots and other presentations shown in this manual may differ from the actual screens and presentations generated by the actual product. Device mount socket For the device mount. Mini-USB connector Connects to the charger or computer. -
Page 4: Power Key
Power key Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will start right after the recorder turns on. You can do the followings using the Power key: ƒ To manually turn the recorder on and off, press and hold the Power key for 2 seconds. -
Page 5: Using The Touch Screen
Using the touch screen To operate your recorder, touch the screen with your fingertip. The device provides the control buttons and system icons on the screen. The on-screen buttons and icons may change depending on your settings and usage of the device. Example Button Description... -
Page 6: Inserting A Memory Card
Inserting a memory card You must insert a memory card (not supplied) before you can start recording. 1. Hold the card by the edges and gently insert it into the slot with the label facing the rear side of the recorder. 2. -
Page 7: Using Your Recorder In A Vehicle
Using your recorder in a vehicle 1. Make sure that your car is parked on a level ground. 2. Follow the instruction below to mount your recorder in a vehicle securely. 3. Connect the car charger to the cigarette lighter. Route the cables through the top ceiling and the A-pillar so that it does not interfere with driving. - Page 8 4. When adjusting the angle of mounting, make sure that the camera’s view is parallel with the level ground, and the ground/sky ratio is close to 6/4. 5. When not using the recorder, follow the instruction below to remove the recorder from the holder.
-
Page 9: Connecting To External Devices
Connecting to external devices Connecting to your computer You can connect the recorder to your computer to access data on the memory card. The Mini-USB connector is located on the right side of the device. Follow the instruction below to connect the recorder to the computer via the USB cable (not supplied). Connecting to a High Definition (HD) device For a better viewing experience, you can connect the recorder to an external viewing device that supports the High Definition (HD) feature via a HD cable (not supplied). -
Page 10: Operating Basics
Operating basics Turning the recorder ON and OFF Complete the installation according to the instructions in the “Using your recorder in a vehicle” section. ƒ Once the vehicle engine is started, the recorder automatically turns on. By default, the recording will automatically start in few seconds after start-up. ƒ... -
Page 11: Recording In Driving Mode
ƒ When you select Automatic, the system will display the time zone setting screen. to select your time zone and tap . The system will set the correct date and time according to the time zone setting. ƒ When you select Manual, the system will display the date and time setting screen. to adjust the value of the selected field;... -
Page 12: Recording In Parking Mode
Event recording By default, if an event happens, such as sudden impact, high-speed driving, an aggressive turn or an accidental crash, the G sensor will prompt the recorder to start an emergency recording. ƒ If you want to manually start an event recording while continuous recording is in progress, tap . -
Page 13: Camera Mode
ƒ If movements were detected and recorded during Parking mode, you will be asked to playback the video when you stop Parking mode. ƒ The parking recordings can be found in the “Parking” category for file playback. Camera mode The recorder allows you to take a photo. ƒ... -
Page 14: Safety Camera Alerts
Safety camera alerts Caution: For legal reasons the safety camera function is not available in all countries. You can receive alerts to warn you about the locations of safety cameras, which will enable you to monitor your speed through these areas. ƒ... -
Page 15: Adding Safety Camera
Adding safety camera NOTE: You can add a custom safety camera only when a GPS fix is established. Your recorder allows you to customise the safety camera database. You can add up to 100 custom safety cameras in your recorder. Follow the steps to configure a custom safety camera: 1. -
Page 16: System Settings
System settings Settings Menu To customise the system settings, tap Button Description File Playback: Plays the recorded videos and photos. For more information on playback, see the "Playback mode" section. Activate: When the Parking mode function is set to ON, you can tap this button to manually start Parking mode while continuous recording is in progress. - Page 17 - Alert Method: Select By Driving Speed or By Speed Limit. - Threshold: Select At Speed Limit, At Speed Limit +5 km/h, or At Speed Limit +10 km/h. - Custom SafetyCam: This option lists all user-added safety cameras which are sorted by created time.
- Page 18 G-Sensor Sensitivity ƒ The G sensor detects the car's movement forwards/backwards (X), to the right/left (Y), and upwards/downwards (Z). In case of an event, the G sensor will prompt the recorder to start recording automatically. You need to adjust the G sensor sensitivity depending on your driving style and road condition.
- Page 19 - Restore to Defaults: Restores system settings to factory defaults. - Version: Displays the software information. Format ƒ Formats a memory card. (All data will be erased.)
-
Page 20: Mivue Manager
Installing MiVue Manager Download MiVue Manager from www.mio.com and follow the on-screen prompts to install it. Playing the recording files 1. Remove the memory card from the recorder and access the card on the computer via a card reader. - Page 21 NOTE: ƒ The Map screen may not display when the computer is not connected to the Internet or when your MiVue model does not support the GPS function. ƒ G sensor chart displays data in 3-axis waveform about the car’s shift forward/ backward (X), to the right/left (Y) and upward/downward (Z).
- Page 22 : Mutes or unmutes the volume. ƒ : Adjusts the volume level. ƒ : Plays the video in full screen. Click to return to the normal view. ƒ : Displays the playback progress. You can click on a point along ƒ...
-
Page 23: For More Information
For more information Caring for your device Taking good care of your device will ensure trouble-free operation and reduce the risk of damage. ƒ Keep your device away from excessive moisture and extreme temperatures. ƒ Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time. -
Page 24: Precautions And Notices
Precautions and notices ƒ For your own safety, do not operate the controls of the product while driving. ƒ A window mount is needed when using the recorder in a car. Make sure that you place the recorder in an appropriate place, so as not to obstruct the driver’s view or deployment of airbags. -
Page 25: About Gps
About the battery CAUTION! This unit contains a non-replaceable internal Lithium Ion battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush, puncture, or dispose of in fire or water. ƒ... -
Page 26: Regulatory Information (Ce)
Regulatory information (CE) For regulatory identification purposes, MiVue 5 Series is assigned a model number of N467. Products with the CE marking comply with the Electromagnetic Compatibility Directive (2004/108/EC) - issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Standards: EN 301 489-1 V1.9.2 : 2011... - Page 27 Do not operate the device while driving. Using this product does not change the requirement for a driver to take full responsibility for his or her behavior. This responsibility includes observing all traffic rules and regulations in order to avoid accidents, personal injury or property damage. MiTAC Europe Ltd www.mio.com...
