Mio MiVue 795 Series User Manual

Hide thumbs Also See for MiVue 795 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MiVue
795 / 798 Series
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MiVue 795 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mio MiVue 795 Series

Summary of Contents for Mio MiVue 795 Series

  • Page 1 User Manual MiVue 795 / 798 Series ™...
  • Page 2 The screenshots in this manual may differ between different operating systems and software versions. You can download the latest User Manual of your product from Mio™ website (www.mio.com). Specifications and documents are subject to change without notice. MiTAC does not warrant this document is error-free.

  • Page 3: Table Of Contents

    Table of Contents Getting to know your dash cam ................4 Using your dash cam in a vehicle ................. 5 Precautions and notices .................. 5 Mounting the dash cam ................... 6 MiVue rear camera ..................7 Using a memory card ................... 8 Formatting a card ....................
  • Page 4 Getting connected ....................16 MiVue Pro app ....................16 Setting up a WIFI connection ................ 17 System settings ....................18 MiVue Manager ....................23 Installing MiVue Manager ................23 Playing the recording files ................23 For more information ..................26 Caring for your device ...................

  • Page 5: Getting To Know Your Dash Cam

    Getting to know your dash cam Note: The screenshots and other presentations shown in this manual may differ from the ones generated by the actual product. Power button Microphone Speaker Device mount socket System indicator Camera lens Mini-USB connector Event button Function keys Shutdown button Memory card slot...

  • Page 6: Using Your Dash Cam In A Vehicle

    Using your dash cam in a vehicle Precautions and notices Do not operate the device while driving. Using this product does not change the requirement for a driver to take full responsibility for his or her behavior. This responsibility includes observing all traffic rules and regulations in order to avoid accidents, personal injury or property damage.

  • Page 7: Mounting The Dash Cam

    Mounting the dash cam Make sure that your car is parked on level ground. Follow the instructions to mount your dash cam in a vehicle securely. 1. Before attaching the device mount to the windscreen, it is recommended to clean the windscreen with rubbing alcohol and make sure that the installation area is free of dust, oil and grease.

  • Page 8: Mivue Rear Camera

    Note: The installation illustrations are for your reference only. The placement of the devices and cables may vary depending on the vehicle model. If you encounter any problems during installation, contact a skilled installer (such as the service personnel of the vehicle) for assistance. MiVue rear camera Depending on your model, your device may support a rear camera (may be sold separately).

  • Page 9: Using A Memory Card

    Using a memory card Note: DO NOT apply pressure to the centre of the memory card. MiTAC does not guarantee the product’s compatibility with memory cards from all manufacturers. Before you start recording, please format the memory card to avoid malfunction caused by files not created by the dash cam. Turn the device off before removing the memory card. You must insert a memory card (not supplied) before you can start recording.

  • Page 10: Restarting The Dash Cam

    Restarting the dash cam Occasionally, you may need to perform a hardware reset when the dash cam stops responding or if it appears to be “frozen” or unresponsive. To restart the dash cam, press and hold the Power button until the system powers off; press the Power button again to turn the dash cam on.

  • Page 11: Function Keys

    Function keys The device provides four function keys to control the corresponding icons displayed on the LCD screen. The keys' functions may vary on different screens. Opens the Menu screen. Enters Parking mode. (Recording screen) Adds a custom safety (speed) camera. Takes a photo.

  • Page 12: Setting The Date And Time

    Setting the date and time To make sure that the date and time of your recordings are correct, check the settings before you begin recording. 1. Press > System > Date/Time. 2. Do one of the following: Select Use GPS time, and then select the time zone of your location. The system will set date and time according to the GPS location.

  • Page 13: Event Recording

    Parking mode Your dash cam supports the parking recording function. You must use an additional power source to record the video during the Parking mode, such as a Mio uninterruptible power cable which is sold separately. For more information on using a Mio power cable, see the provided documentation in its package.

  • Page 14: Camera Mode

    In the Parking mode, parking recordings could be triggered only when movements or vibrations are detected. The parking recording will save the duration from seconds before the event until seconds after the event. When your memory card fills up with parking recordings, it will automatically record over the oldest existing files in this category.

  • Page 15: Playback Mode

    Playback mode To select a video or photo for playback: 1. Press > File Playback. 2. Select the desired type. 3. Press to select the desired file from the list and then press start playback. 4. During playback, you can: Press to return to the list.

  • Page 16: Safety Camera Alerts

    Safety camera alerts Note: For legal reasons, the safety camera function is not available in all countries. You can receive alerts to warn you about the locations of safety (speed) cameras which will enable you to monitor your speed through these areas.

  • Page 17: Updating Safety Camera Data

    MiTAC does not warrant that all types and locations of safety camera data are available as cameras may be removed, relocated or new cameras installed. Occasionally, MiTAC may offer you updates of safety camera data. Visit the Mio website for available downloads and follow the instructions to complete update.

  • Page 18: Setting Up A Wifi Connection

    5. Once the devices are connected, the screen will display the main page ( Note: The WIFI connection between your Mio and smartphone is not Internetenabled. You can check the WIFI connection status by the WIFI icon on the dash cam.

  • Page 19: System Settings

    The dash cam is connected to the smartphone but not paired with the MiVue Pro app yet. On your smartphone, open the MiVue Pro app and keep it awake. You can now transfer videos by pressing the Event button. System settings Note: Not all setting items and options are available for all models.
  • Page 20 Front Tyre Sensors: Sets the minimum/maximum pressure and maximum temperature for the front tyres. Rear Tyre Sensors: Sets the minimum/maximum pressure and maximum temperature for the rear tyres. Sensor Location: Sets the sensors' locations. Learning Mode: When new TPMS sensors are installed, use this option for the dash cam to detect the new sensors.
  • Page 21 Driver Fatigue Alert: Once enabled, the system will remind you to take a break for a long-distance drive (2 hours, 3 hours or 4 hours). The default setting is Off. Eco Drive Indicator: Once enabled, the system will display the Eco drive indicator on the screen.
  • Page 22 Parking Mode Allows you to change the settings of Parking mode. The available settings include: Detection: When enabled, the dash cam will automatically start recording when it detects movements or if an event happens in Parking mode. Detection Method: Sets the parking detection method to Only G-sensor, Only Motion or Both Motion &...
  • Page 23 G-Sensor Sensitivity: Sets the sensitivity level of the G sensor that allows automatic triggering of the event recording while continuous recording is in progress. Stamps: Sets the information (Coordinates or G-Sensor) that will be displayed on the recorded video. Speed stamp: Displays the driving speed on the recorded video. Text stamp: Displays customisable text information.

  • Page 24: Mivue Manager

    Note: Not all features are available for every model. Installing MiVue Manager Download MiVue Manager from the Support page of Mio website (www.mio.com/ support) and follow the on-screen prompts to install it. Make sure to download the correct software version (Windows or Mac) according to your computer's operating system.
  • Page 25 You can select the file type to display: Event / Normal / Parking. To display all files in the current folder, click All. To return to the calendar view, click Calendar. 3. Double-click the desired file on the file list to start playback. 4.
  • Page 26 6. The tool bar allows you to do the following: Selects the folder that stores the recording files. Previews and prints the current video image. Saves the selected files to the specified location on your computer. Captures and saves the current video image to the specified location on your computer.

  • Page 27: For More Information

    For more information Caring for your device Taking good care of your device will ensure trouble-free operation and reduce the risk of damage. Keep your device away from excessive moisture and extreme temperatures. Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time.

  • Page 28: Safety Precautions

    To discourage theft, do not leave the device and accessories in plain view in an unattended vehicle. Overheating may damage the device. Safety precautions About charging Use only the charger supplied with your device. Use of another type of charger may result in malfunction and/or danger.

  • Page 29: About Gps

    Caution! Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Replace only with the same or equivalent type recommended by the manufacturer. The battery must be recycled or disposed of properly. Use the battery only in the specified equipment.

  • Page 30: Declaration Of Conformity

    EN 61000-4-2: 2009 and IEC 61000-4-2: 2008 EN 61000-4-3: 2006 + A1: 2008 + A2: 2010 and IEC 61000-4-3: 2006 + A1: 2007 + A2: 2010 EN 61000-4-4: 2012 and IEC 61000-4-4: 2012 EN 61000-4-5: 2006 and IEC 61000-4-5: 2005 EN 61000-4-6: 2009 and IEC 61000-4-6: 2008 EN 61000-4-8: 2010 and IEC 61000-4-8: 2009 EN 61000-4-11: 2004 and IEC 61000-4-11: 2004...

This manual is also suitable for:

Mivue 798 seriesC380
