Each input circuit has four screw terminals associated with it.
These terminals are shown in Figure 4-5 to the right.
To connect a voltage signal to the input circuit you only use
three screw terminals; these are:
+SENSE Signal high, or CH HI on a DAS board
-SENSE Signal low, or CH LO on a DAS board
-IEXC
Low Level Ground (LLGND)

4.7.2 Floating Differential

A floating differential input has two wires from the
signal source and a 10K ground reference resistor
installed at the CIO-EXP-RTD16 input. The two
signals from the signal source are Signal High and
Signal Low. The reference resistor is connected
between the CIO-EXP-RTD16 -SENSE and -IEXC
pins (Figure 4-6).
A floating differential hookup is handy when the signal
source is floating with respect to ground, such as a
battery-powered device. The floating differential input
will reject up to 10V of EMI energy on the signal
wires.
Verify that the signal source is really floating. Check it with a voltmeter before risking the
CIO-EXP-RTD16 and PC!
Figure 4-5. Single-Ended Voltage Input
Add 10K
Resistor
Figure 4-6. Floating-Differential Voltage Input
:
CAUTION
10
Add Jumper
CH0
Voltage
Signal-Low
Signal-High
Source
(Gnd.)
Single-Ended Voltage Input
Voltage
Signal-Low
Source
Floating-Differential Voltage Input
Signal-High
