Kyocera FS-C5150DN Service Manual page 40

Service items
No.
(22) Mac address
(23) The last sent date and time
(24) Transmission address
(25) Destination information
(26) Area information
(27) Margin settings
(28) Top offset for each paper source MP tray/Paper feeder 1/Paper feeder 2/
(29) Left offset for each paper source MP tray/Paper feeder 1/Paper feeder 2/
(30) Margin/Page length/Page width
settings
(31) Life counter (The first line)
Life counter (The second line)
(32) Panel lock information
(33) USB information
(34) Paper handling information
(35) Color printing double count
mode
(36) Black and white printing double
count mode
(37) Billing counting timing
(38) Temperature (machine inside)
(39) Temperature (machine outside)
(40) Relative temperature
(machine outside)
(41) Absolute temperature
(machine outside)
(42) Fixed assets number
(43) Job end judgment time-out time
(44) Job end detection mode
Description
1-3-6
Description
Supplement
-
-
-
-
-
Top margin/Left margin
Paper feeder 3/Duplex/Page rotation
Paper feeder 3/Duplex/Page rotation
Top margin integer part/Top margin decimal part/
Left margin integer part/Left margin decimal part/
Page length integer part/Page length decimal part/
Page width integer part/Page width decimal part
Machine life/MP tray/Cassette/Paper feeder 1/
Paper feeder 2/Paper feeder 3/Duplex
Drum unit K/Drum unit C/Drum unit M/Drum unit Y/
Intermediate transfer unit/Developing unit K/
Developing unit C/Developing unit M/
Developing unit Y/Maintenance kit
0: OFF/1: Partial lock/2: Full lock
U00: Not installed/U01: Full speed/U02: Hi speed
0: Paper source unit select/1: Paper source unit
0: All single counts
3: Folio, Single count, Less than 330 mm (length)
0: All single counts
3: Folio, Single count, Less than 330 mm (length)
-
-
-
-
-
-
-
-
2KT/2KV
