Kyocera FS-C5150DN Service Manual page 152

EPWB
PAPVOL1
YC21-3
PAPVOL2
YC21-2
LIFTSEN
YC21-4
FEDCLDRN
YC3-3
LMOTDRN
YC27-1
FEMOTRDYN
YC3-6
FEMOTCLK
YC3-7
FEMOTREN
YC3-8
Figure 2-1-3 Cassette paper feed section block diagram
*: 26/28 ppm model only
CPWB
YC1-3
YC1-4
YC1-2
PFCL
LM
2-1-3
PS1
PS2*
LS
5
PFM
4
3
2KT/2KV
