12. Remove all connectors from the main
PWB.
13. Remove two screws and then remove
the wire holder.
YC9
YC13
YC14
YC8
YC6
YC7
YC12
Main PWB
Figure 1-5-47
Wire holder
Figure 1-5-48
1-5-32
2KT/2KV
Main PWB
YC4
Screw
Screw
