Kyocera FS-C5150DN Service Manual page 107

3. Remove the top cover (see page 1-5-3).
4. Remove the right rear cover, right cover
and right lower cover (see page 1-5-5).
5. Remove the left rear cover, left cover
and left lower cover (see page 1-5-8).
6. Release four hooks and then remove
the inner cover.
Inner cover
Hook
Hook
Figure 1-5-17
1-5-11
Hook
Hook
Inner cover
2KT/2KV
