5. Open the memory cover and then
remove it.
6. Open the waste toner cover.
7. Push the lock release button and then
remove the waste toner box.
Figure 1-5-8
Figure 1-5-9
1-5-6
2KT/2KV
Memory cover
Lock release button
Waste toner
cover
Waste toner box
