Icom IC-M72 Service Manual page 19

[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R415 7030005090 S.RES ERJ2GEJ 104 X (100 k
R416 7030005160 S.RES ERJ2GEJ 105 X (1 M
R417 7030005120 S.RES ERJ2GEJ 102 X (1 k
R419 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
R430 7030005090 S.RES ERJ2GEJ 104 X (100 k
R431 7030005090 S.RES ERJ2GEJ 104 X (100 k
R432 7030005090 S.RES ERJ2GEJ 104 X (100 k
R433 7030007340 S.RES ERJ2GEJ 153 X (15 k
R434 7030005230 S.RES ERJ2GEJ 334 X (330 k
R435 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
R436 7030006610 S.RES ERJ2GEJ 394 X (390 k
R437 7030005220 S.RES ERJ2GEJ 223 X (22 k
R438 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
R439 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
R440 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
R441 7030005090 S.RES ERJ2GEJ 104 X (100 k
R442 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
R450 7030008290 S.RES ERJ2GEJ 183 X (18 k
R451 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
R452 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
R453 7030005120 S.RES ERJ2GEJ 102 X (1 k
R454 7030005170 S.RES ERJ2GEJ 474 X (470 k
R481 7030005160 S.RES ERJ2GEJ 105 X (1 M
R483 7030005530 S.RES ERJ2GEJ 100 X (10)
R489 7030005050 S.RES ERJ2GEJ 103 X (10 k
R491 7030005050 S.RES ERJ2GEJ 103 X (10 k
R493 7030005050 S.RES ERJ2GEJ 103 X (10 k
R495 7030005050 S.RES ERJ2GEJ 103 X (10 k
R496 7030005050 S.RES ERJ2GEJ 103 X (10 k
R497 7030005050 S.RES ERJ2GEJ 103 X (10 k
R498 7030009150 S.RES ERJ2GEJ 824 X (820 k
R499 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
R500 7030007060 S.RES ERJ2GEJ 684X (680 k
R501 7030008300 S.RES ERJ2GEJ 184 X (180 k
R502 7030010040 S.RES ERJ2GEJ-JPW
R505 7030005090 S.RES ERJ2GEJ 104 X (100 k
R512 7030005120 S.RES ERJ2GEJ 102 X (1 k
R520 7030010040 S.RES ERJ2GEJ-JPW
R521 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
7030010040 S.RES ERJ2GEJ-JPW
R540 7030005700 S.RES ERJ2GEJ 274 X (270 k
R541 7030005050 S.RES ERJ2GEJ 103 X (10 k
C160 4030018240 S.CER ECJ0EB1E562K
C170 4030017460 S.CER ECJ0EB1E102K
C171 4030017680 S.CER ECJ0EC1H820J
C174 4030017460 S.CER ECJ0EB1E102K
C175 4030017460 S.CER ECJ0EB1E102K
C176 4030017460 S.CER ECJ0EB1E102K
C177 4030016930 S.CER ECJ0EB1A104K
C178 4030018890 S.CER ECJ0EB0J224K
C179 4030017450 S.CER ECJ0EB1E271K
C180 4030017450 S.CER ECJ0EB1E271K
C181 4030016930 S.CER ECJ0EB1A104K
C200 4030016790 S.CER ECJ0EB1C103K
C202 4030016930 S.CER ECJ0EB1A104K
C205 4030016960 S.CER ECJ0EB1C183K
C206 4030017460 S.CER ECJ0EB1E102K
C207 4030016930 S.CER ECJ0EB1A104K
C222 4030016790 S.CER ECJ0EB1C103K
C224 4550006250 S.TAN TEESVA 1A 106M8R
C225 4030018890 S.CER ECJ0EB0J224K
C226 4030016790 S.CER ECJ0EB1C103K
C227 4550006250 S.TAN TEESVA 1A 106M8R
C228 4030017460 S.CER ECJ0EB1E102K
C229 4030017460 S.CER ECJ0EB1E102K
C230 4550006470 S.TAN TEESVB2 1D 106M8R
C231 4030018870 S.CER ECJ0EF0J105Z
C233 4030016790 S.CER ECJ0EB1C103K
C240 4030017460 S.CER ECJ0EB1E102K
C250 4030016790 S.CER ECJ0EB1C103K
4030016930 S.CER ECJ0EB1A104K
C251 4550006250 S.TAN TEESVA 1A 106M8R
C252 4030017460 S.CER ECJ0EB1E102K
C254 4030016790 S.CER ECJ0EB1C103K
C257 4030016790 S.CER ECJ0EB1C103K
C260 4030018910 S.CER C1608 JB 0J 475K-T
C261 4030016930 S.CER ECJ0EB1A104K
C262 4030016790 S.CER ECJ0EB1C103K
C263 4030016790 S.CER ECJ0EB1C103K
C264 4030017770 S.CER ECJ0EB1E332K
C265 4030017420 S.CER ECJ0EC1H470J
[scramble]=[USA-1], [SEA-1], [AUS-1]
H/V
M.
LOCATION
[scramble] only B 32/18.6
[scramble] only B 63.8/4.2
[scramble] only B 62.9/5.1
[scramble] only B 36.8/20
B 10.2/33
B 11.7/33.9
B 14.8/32.2
B 11.8/6.8
B 10.5/5.5
B 6.7/2.7
B 7.7/2.7
B 7.7/4.3
B 7.7/5.6
B 13.8/6.8
B 13.7/5.5
B 16.3/6.7
B 12.1/5.5
B 26.4/25.8
B 28/25.4
B 29.3/25.4
B 28/26.3
Except [AUS] only B 29.2/28.2
B 85/25.8
B 85/27.4
B 72.9/25.3
B 78.3/24.9
B 76.4/25.5
B 78.3/23.9
B 79.5/22.7
B 80.5/21.5
B 79.3/6.3
B 80.9/7.1
B 82/5.9
B 81.1/5.9
[scramble] only B 72.9/26.2
B 64.8/18.6
[scramble] only B 66/3
B 10.4/38.9
Except [AUS] B 11.3/38.9
[AUS] B 11.3/38.9
B 27.2/10.2
B 27.8/6.9
B 50.3/23
B 51.3/38.1
B 52.3/27.9
B 54.6/28.3
B 56.1/26.3
B 54.9/27.1
B 50.1/38.9
B 50.1/37.9
B 53.1/38.1
B 54.9/38.1
B 52.2/37.3
B 19.9/33.5
B 22.4/25.9
B 19.8/28.6
B 19.8/26.8
B 21.1/25.4
B 28.3/16.7
B 28.3/21.7
B 23.4/17.3
B 21.6/14.5
B 20.8/16.1
B 23.2/14.5
B 26.2/6.7
B 23.8/8.9
B 31.8/5.5
B 30.7/16.6
B 27.2/8.6
[AUS] B 6.5/36.3
Except [AUS] B 6.5/36.3
B 12.9/39.2
B 10.4/40.5
B 21/37.5
B 19.9/37.8
B 24/6.6
B 35.3/25.6
B 36.3/36
B 17.7/23.5
B 32.3/37.9
B 29.4/33.9
6 - 2
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
C266 4030016950 S.CER ECJ0EB1A473K
C267 4030018860 S.CER ECJ0EB0J105K
C280 4030018860 S.CER ECJ0EB0J105K
C282 4550007080 S.TAN TEESVA 1C 106M8R
C283 4030016930 S.CER ECJ0EB1A104K
C284 4030017460 S.CER ECJ0EB1E102K
C285 4030016930 S.CER ECJ0EB1A104K
C286 4550006250 S.TAN TEESVA 1A 106M8R
C287 4030017700 S.CER ECJ0EC1H151J
C288 4030016950 S.CER ECJ0EB1A473K
C289 4510009010 S.ELE EEE1AA221P
C300 4030017770 S.CER ECJ0EB1E332K
C340 4030016790 S.CER ECJ0EB1C103K
C341 4030017030 S.CER ECJ0EB1A273K
C350 4030017460 S.CER ECJ0EB1E102K
C351 4030017420 S.CER ECJ0EC1H470J
C352 4030017420 S.CER ECJ0EC1H470J
C376 4030016930 S.CER ECJ0EB1A104K
C377 4030017740 S.CER ECJ0EB1E821K
C378 4030017780 S.CER ECJ0EB1E472K
C379 4030017500 S.CER ECJ0EC1H560J
C401 4030018870 S.CER ECJ0EF0J105Z
C402 4030018870 S.CER ECJ0EF0J105Z
C403 4550006250 S.TAN TEESVA 1A 106M8R
C404 4030016790 S.CER ECJ0EB1C103K
C405 4030016930 S.CER ECJ0EB1A104K
C410 4030018860 S.CER ECJ0EB0J105K
C411 4030018860 S.CER ECJ0EB0J105K
C412 4030018860 S.CER ECJ0EB0J105K
C413 4030016930 S.CER ECJ0EB1A104K
C414 4030016930 S.CER ECJ0EB1A104K
C415 4030018860 S.CER ECJ0EB0J105K
C416 4030018860 S.CER ECJ0EB0J105K
C417 4030016790 S.CER ECJ0EB1C103K
C418 4030016790 S.CER ECJ0EB1C103K
C419 4030016930 S.CER ECJ0EB1A104K
C420 4030017650 S.CER ECJ0EC1H270J
C421 4030017650 S.CER ECJ0EC1H270J
C422 4030017690 S.CER ECJ0EC1H121J
C423 4030016930 S.CER ECJ0EB1A104K
C424 4030018860 S.CER ECJ0EB0J105K
C425 4030018860 S.CER ECJ0EB0J105K
C430 4030018860 S.CER ECJ0EB0J105K
C431 4030018860 S.CER ECJ0EB0J105K
C432 4030016930 S.CER ECJ0EB1A104K
C433 4030017460 S.CER ECJ0EB1E102K
C434 4030016960 S.CER ECJ0EB1C183K
C435 4030016960 S.CER ECJ0EB1C183K
C436 4030017730 S.CER ECJ0EB1E471K
C437 4030017460 S.CER ECJ0EB1E102K
C438 4030016930 S.CER ECJ0EB1A104K
C439 4030016930 S.CER ECJ0EB1A104K
C450 4030018860 S.CER ECJ0EB0J105K
C451 4030018860 S.CER ECJ0EB0J105K Except [AUS] only B
C482 4030017400 S.CER ECJ0EC1H220J
C483 4030017400 S.CER ECJ0EC1H220J
C488 4550006250 S.TAN TEESVA 1A 106M8R
C489 4030016790 S.CER ECJ0EB1C103K
C490 4030016790 S.CER ECJ0EB1C103K
C491 4030016950 S.CER ECJ0EB1A473K
C492 4030017460 S.CER ECJ0EB1E102K
C493 4030016950 S.CER ECJ0EB1A473K
C494 4030016950 S.CER ECJ0EB1A473K
C495 4030017040 S.CER ECJ0EB1A333K
C496 4030016950 S.CER ECJ0EB1A473K
C497 4030016950 S.CER ECJ0EB1A473K
C498 4030016950 S.CER ECJ0EB1A473K
C499 4030016950 S.CER ECJ0EB1A473K
C500 4030016930 S.CER ECJ0EB1A104K
C502 4030018900 S.CER ECJ0EB0J474K
C503 4030018900 S.CER ECJ0EB0J474K
C504 4030018900 S.CER ECJ0EB0J474K
C505 4030018900 S.CER ECJ0EB0J474K
J100 6510025130 S.CNR 30P9.0-JMCS-G-B-TF (N)
J251 6510021900 S.CNR BM02B-ASRS-TF
J260 6510022690 S.CNR 06FLT-SM1-TB Except [AUS] only B
J300 6510025140 S.CNR 10FLT-SM1-TB
DS240 5040003010 S.LED SML-A12WT
DS241 5040003010 S.LED SML-A12WT
DS242 5040002310 S.LED SML-311YTT86
DS243 5040002310 S.LED SML-311YTT86
DS250 5040003010 S.LED SML-A12WT
DS251 5040003010 S.LED SML-A12WT
DS252 5040002310 S.LED SML-311YTT86
DS253 5040002310 S.LED SML-311YTT86
DS480 5030002910 LCD L5-0213TVM
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V
M.
LOCATION
B 30.3/37.7
B 30/36.5
B 16.1/28.4
B 11.9/11.6
B 15/16.7
B 15/17.6
B 19.2/29.5
B 19.9/12.3
B 15.5/8.1
B 10.3/9.3
B 68.6/29.9
B 23.9/24.6
B 71.8/34.6
B 69.9/39
B 53.5/2
B 77.4/35
B 78.7/34.1
B 18.7/40.8
B 23.6/28.9
B 20.8/30.7
B 20/32.2
B 17.3/16.8
B 17.7/31.8
B 25/19.8
B 23/23.4
B 15.2/20.4
[scramble] only B 49.6/8
[scramble] only B 49.6/11.2
[scramble] only B 51.3/15.3
[scramble] only B 32/21.8
[scramble] only B 36/23
[scramble] only B 36.8/16.8
[scramble] only B 36.8/18.4
[scramble] only B 36.8/21.6
[scramble] only B 31.1/18.6
[scramble] only B 55.6/16.3
[scramble] only B 67.1/4.3
[scramble] only B 62.2/4.2
[scramble] only B 62.3/11.6
[scramble] only B 64.9/5.1
[scramble] only B 49.6/9.6
[scramble] only B 49.8/4.8
B 12.5/35.1
B 14.8/40.8
B 8.9/34
B 12/31.8
B 12.8/6.8
B 10.5/7.5
B 10.5/6.5
B 7.7/6.6
B 14.8/6.8
B 6.7/4.3
B 28/27.5
29.3/27
B 85.9/25.8
B 85/24.2
B 65/21.6
B 66.6/21.8
B 66.5/24.4
B 85.3/22.9
B 85.6/21.1
B 85.5/19
B 85.6/15.1
B 85.9/16.9
B 85.5/18.1
B 85.2/7.9
B 85.2/6.2
B 84.3/6
B 83.4/6.4
B 81.7/8.2
B 78.5/4.7
B 77.6/4.7
B 82.3/9.4
B 61.3/20.3
T 6.6/3
65.3/40.1
B 76.6/29.7
T 63.5/2.1
T 73.5/2.1
T 38.9/12.3
T 38.9/30.3
T 63.5/40.4
T 73.5/40.4
T 23.6/11.8
T 23.6/30.8
S.=Surface mount
