5-2 SOFTWARE ADJUSTMENT (FREQUENCY)
Select the adjustment item with [↑] / [↓] keys, then set the value with [←] / [→] keys on the connected PC.
ADJUSTMENT
PLL LOCK
1 • Operating CH. : 16
VOLTAGE
• Receiving
(Verify)
2 • Operating CH. : 16
• Connect a dummy load or RF power
meter to the antenna connector.
• Transmitting
REFERENCE
1 • Operating CH. : 16
• Connect the RF power meter or a 50 Ω
FREQUENCY
[Ref Freq]
dummy load to the antenna connector.
• Transmitting
ADJUSTMENT CONDITION
NOTE: The above screen is an example.
Each transceiver has its own specific values.
MEASUREMENT
UNIT
OPERATION
PC
Click the "I/O check button" on
screen
the CS-M72 ADJ's screen (see
page 5-3) to open the I/O check
window as below.
Top
Loosely couple the frequency
Panel
counter to the antenna conector.
5 - 4
VALUE
1.65–2.65 V
(Verify)
1.75–2.75 V
(Verify)
156.8000 MHz
PLL LOCK VOLTAGE
