DISPLAY LAYOUT

2
1
9
8
H
OME
1
HOME ICON:
MENU TITLE:
2
3
MōVI STATUS:
Booting:
Connected:
GPS STATUS:
4
MōVI BATTERY LEVEL:
5
3
4
5
6
7
S
CREEN
Return to the Home menu at any time by scrolling (with the Menu Select knob) to and clicking on the Home
icon in the top left corner of the display.
The title of the currently active menu is displayed here.
When connected to a MōVI, this icon will display the MōVI Status:
The MōVI is starting up. Keep the camera stationary while this icon is displayed for the IMU to properly initialize.
Error:
The MōVI is connected, but an error has occured. Check the MōVI Monitor menu for more information on the
cause of the error, or try restarting the MōVI.
The MōVI is connected and running, and the MōVI Controller is receiving live telemetry.
When the Mōvi acquires GPS lock, the GPS icon () is displayed and GPS-based acceleration compensation
(to minimize horizon drift during high-acceleration movement) is active.
The state of charge of the MōVI battery. Check the MōVI Monitor menu for the exact battery voltage.
2
1
9
8
T
M
YPICAL
3
4
5
6
10
S
ENU
CREEN
