FOLLOW-FOCUS INTEGRATION:
The MōVI Controller can integrate with wireless follow-focus systems from Redrock Micro and Hocus Products with an optional Auxiliary Transmitter. The Auxiliary
Transmitter uses the same hardware as the MōVI Controller Receiver and communicates directly with the follow-focus system. It connects to the Auxiliary Data Port
on the MōVI Controller. The range of the Auxiliary Transmitter is similar to that of the primary radio link to the MōVI (approx. 1200ft outdoor/line-of-sight).
REDROCK MICRO MICROREMOTE
To enable the Auxiliary Transmitter to communicate with a Redrock Micro microRemote Basestation:
1.
Set the Auxiliary Transmitter to microRemote Auxiliary Transmitter mode by following the instructions in the Auxiliary Transmitter section.
2.
Use the Channel Switch on the Auxiliary Transmitter to set the channel to be the same as that of the microRemote Basestation. This can and
should be set to a different channel than the primary radio link to the MōVI to prevent interference. See the channel mapping table in the Radio
Config section.
3.
Select "microRemote" in
Note: Only channels 1 through C are available. Channels 0, D, E, and F are reserved for low-power transmitters.
HOCUS PRODUCTS AXIS 1
To enable the Auxiliary Transmitter to communicate with a Hocus Products Axis 1 Digital Receiver:
1.
Set the Auxiliary Transmitter to Axis 1 Auxiliary Transmitter Mode mode by following the instructions in the Auxiliary Transmitter section.
12V DC OUTPUT:
2.
Use the Channel Switch on the Auxiliary Transmitter to set the channel to be the same as that of the Axis 1 Digital Receiver. This can and
should be set to a different channel than the primary radio link to the MōVI to prevent interference. See the channel mapping table in the Radio
Config section.
3.
Select "Axis 1" in
FIZ Config::System
Note: Only channels 1 through C are available. Channels 0, D, E, and F are reserved for low-power transmitters.
FIZ Config::System
on the MōVI Controller.
on the MōVI Controller.
