RADIO MODE

By default, the MōVI Controller uses a proprietary bidirectional communication protocol.
MōVI:
To add compatibility with other systems, it can be configured to output a Spektrum DSMX 2048 satellite receiver signal via the 3-pin Spektrum connector on
DSMX 2048:
the MōVI Controller Receiver. The channel mapping in DSMX 2048 mode is shown below.
In this mode, the MōVI Controller relays raw data between the Receiver and a host computer via USB. This can be used to control the MōVI from a computer
TETHER/RX FW:
interface, or to update the Receiver firmware.
SPEKTRUM DSMX 2048 CHANNEL
FIZ CONFIG
Configure the operation of wireless Focus-Iris-Zoom (FIZ) systems in this menu. For more information on supported systems, see the Follow-Focus Integration section.
Choose between supported wireless follow-focus systems. See Follow-Focus Integration section for more details on supported systems. Choose
SYSTEM
None to disable the Auxiliary Transmitter and allow follow-focus control from a separate handset.
Choose which user input axis is active on the Auxiliary Transmitter output. The Focus Knob, Zoom Rocker, and Iris Knob can each be optionally
INPUT
selected for output to a single-axis system. For direction reversal, see the Tx Config menu section above.
To save FIZ configuration settings, use
Aileron
Elevator
Throttle
Rudder
Gear
Aux1
Aux2
Tx Config::Tx Action::Save.
MŌVI CONTROLLER FUNCTION
Pan
Tilt
Pan Speed
Roll Trim
TK Rec Start/Stop
TK Mode Switch (Dual, Majestic, Kill)
Tilt Speed
