GL220 Convenient Functions
The GL220 has various functions that enable it to be used more effectively.
The selected three functions are described with details in the following.

Trigger Functions to Control Data Capture Start/Stop Operations

Trigger functions can be used to control the timing of the start of a data capture operation,
and the timing of the end of a data capture operation. and the timing of the end of a data capture operation.
Points to
For example...
Remember
The trigger function performs operations such as the following:
• Start data capture when the voltage exceeds 1 V
• Stop data capture at 1:00 pm
• Perform control via external input
Here data capture is started in the condition as "Start data capture when the CH 1 Here data capture is started in the condition as "Start data capture when the CH 1 Here data capture is started in the condition as "Start data capture when the CH 1
temperature exceeds 20ºC".
(1) Press the MENU key and open the "TRIG" menu. (1) Press the MENU key and open the "TRIG" menu.
(2) Move the cursor to "Start Source" and select "Level". (2) Move the cursor to "Start Source" and select "Level". (2) Move the cursor to "Start Source" and select "Level".
(3) Move the cursor to the "Mode" parameter for the CH 1, and then select "Hi". (3) Move the cursor to the "Mode" parameter for the CH 1, and then select "Hi". (3) Move the cursor to the "Mode" parameter for the CH 1, and then select "Hi".
