SPECIFICATION
Monitor

Specifications

Picture Tube
Viewable Image Size:
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight (Net)
Environmental Considerations
Operating Temperature:
Storage Temperature:
NOTE: Technical specifications are subject to change without notice.
N0501
Monitor
Diagonal: 38cm(15inch)
35cm(13.8inch)
Radius: 1080mm
Video: ANALOG 0.7Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/
Negative
Vertical sync. Positive/Negative
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 70 kHz
Vertical: 55 Hz to 120 Hz
640 × 480 @ 60 to 120 Hz
800 × 600 @ 55 to 110 Hz
832 × 624 @ 55 to 106 Hz
1024 × 768 @ 55 to 87 Hz ... ...
1152 × 870 @ 55 to 77 Hz
1280 × 1024 @ 55 to 66 Hz
Horizontal: 270mm
Vertical: 203mm
280mm
210mm
AC 100 - 240V, 50 - 60Hz
1.3A @ 100 - 240V
360(W ) × 380(H) × 381(D) mm
12.5 kg
0° C to + 35° C
Humidity: 30% to 80%
Altitude: 0 to 3000 m
-20° C to + 60° C
Humidity: 10% to 90%
Altitude: 0 to 13700 m
Notes
90° deflection, 0.28mm trio dot pitch, medium
short persistence phosphor, multi-layered, anti-
static screen coating, semi-tint screen, Invar
Shadow Mask.
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
