Table Of Contact Id Event Codes; Communication Programming - First Alert FA142C Installation Instructions Manual

Code Definition
110 Fire Alarm
121 Duress
122 Alarm, 24-hour Silent
123 Alarm, 24-hour Audible Panic
131 Alarm, Perimeter, Burg.
132 Alarm, Interior, Burg.
134 Alarm, Entry/Exit, Burg.
135 Alarm, Day/Night, Burg.
150 Alarm, 24 Hour Auxiliary
301 AC Power
302 Low System Battery/Battery Test Fail
333 Expansion Module Fail
353 Long Range Radio Trouble
373 Fire Loop Trouble

Communication Programming

Introduction
This section provides instructions for programming those fields that affect communications
between the control and the central station.
Programming Procedure
Fields 40, 41, 42:
Enter up to the number of
digits shown. Do not fill
unused spaces.
Enter 0–9,
# + 11 for ' '
# + 12 for '#'
# + 13 for a pause
(2 secs)
Field 43 is also
used as the Long
Range Radio
Subscriber Account
Number

TABLE OF CONTACT ID EVENT CODES

1. With at least one Alpha keypad (FA550KP) connected to the system,
power up the system. If necessary, refer to the FINAL POWER UP
section for the power-up procedure. If you had previously connected the
AC transformer to the control panel, you need only plug in the
transformer (to 120VAC outlet) to power up the system.
2. Enter the programming mode by keying the following on the Alpha
keypad: Installer code (4 1 1 1) + 8 + 0.
Press 40 PABX ACCESS CODE
Enter up to 4 digits if PABX is needed to access an outside line. If fewer than
4 digits are needed to be entered, exit by pressing [ ] and next field number
(e.g., 41). To clear entries from field, press 40 .
Press 41 PRIMARY PHONE No .
Enter up to 12 digits. If fewer than 12 digits entered, exit by pressing [ ] and
next field number (e.g., 42). To clear entries from field, press 41
Press 42 SECONDARY PHONE No.
Enter up to 12 digits. If fewer than 12 digits entered, exit by pressing [ ] and
next field number (e.g., 43). To clear entries from field, press 42
the Paging feature, enter the pager number as the secondary phone
number.
Press 43 SUBSCRIBER ACCOUNT. No.
Central Station Account Number).
Enter 0–9; # + 11 for B; # + 12 for C; # + 13 for D; # + 14 for E; # + 15 for F
(default).
Enter as the fourth digit if a 3-digit account number (for 3+1 dialer reporting
format) is used. Enter 0 as the first digit of a 4-digit account number for Nos.
0000–0999. End field by pressing
See the blank Programming Form in the separate Programming Guide for
examples of Account No. entries.
– 72 –
Code Definition
374 Exit Error Alarm
380 Trouble (Global)
383 RF Sensor Tamper
384 RF Sensor Low Battery
401 O/C by User
406 Cancel by User
407 Remote Arm/Disarm (Download)
408 Quick Arm AWAY/MAX
441
Armed STAY/INSTANT, Quick Arm
STAY/INSTANT
570 Bypass
601 Test, Manually Triggered
602 Periodic Test
606 AAV to follow
(and press next field).
.
. If using
