1. Make 12V (+) and (–) and data in and data out connections from the Phone
Module to the control, using the connector cable supplied with the Phone
Module (see Figure 12).
Color Lead
GREEN
BLACK
RED
YELLOW
2. Insert the keyed connector at the other end of the connector cable into the
mating header on the Phone Module (see diagram on next page for location
of the header).
3. Connect terminals 1 through 5 on the Phone Module as shown in the Wiring
Table and in the FA4285 wiring diagram that follows.
Use an RJ31X jack (CA38A in Canada) with a direct-connect cord and make
all connections exactly as shown. If the leads on the direct-connect cord are
too short to reach their assigned terminals, splice additional wires to them, as
required.
FA4285 Terminal
1: Phone In (Tip)
2: Phone In (Ring)
3: Phone Out (Tip)
4: Phone Out (Ring)
5: Ground
6: Not Used
7: Not Used
If no touch tones are produced following access to the security system from
on-premises (this problem may arise in rare cases), it may be necessary to
reverse the wires connected to terminals 3 and 4 on the Phone Module and
the wires connected to terminals (17) & (18) on the control. The wiring
diagram shows the wiring connections that will provide proper operation in
most cases.

Caller ID Units

If the telephone system on the premises includes a stand-alone Caller ID unit,
connect the ID Caller unit directly to the "Handset" terminals (17 &18) on the
control, as shown in FA4285 Phone Module Wiring Connections diagram that
follows.
If the telephone has a built-in Caller ID unit, the Caller ID function may not work.
Terminal On Control *
DATA IN (terminal 6)
AUX – (terminal 4)
AUX + (terminal 5)
DATA OUT (terminal 7)
FA4285 WIRING TABLE
Connects to:
Terminal (17) on control.
Terminal (18) on control.
BROWN lead from direct-connect cord.
GRAY lead from direct-connect cord.
Earth ground terminal (21) on control.
– 51 –
*
These are the same connections as
those used for remote keypads
.
