2. Attach the Red and Black wires on the battery connector cable as follows:
a) Red to the positive (+) battery tab on the control board.*
b) Black to the negative (–) battery tab on the control board.*
*
3. Attach the Red and Black wires at the other end of the battery connector
cable to the battery, as follows:
a) Red to the positive (+) terminal on the battery.
b) Black to the negative (–) terminal on the battery.
AUXILIARY DEVICE CURRENT DRAW WORKSHEET
DEVICE USED
FA210KP Keypad
FA250KP Keypad
FA550KP Keypad
4281/5881/5882 Type RF Receiver
4204 Relay Module
4219 Zone Expander Module
4229 Zone Expander/Relay Module
FA4285 Phone Module
Long Range Radio
(Current available from Aux. terminals = 500mA max.)
‡
Figures are for relays OFF/relays ON.
If using hard-wire de vices such as PIRs, refer to the specifications for that particular unit's cur rent
draw, and include on worksheet.
**
In UL installations, maximum current draw from the Auxiliary Output and the Alarm Output combined
must not exceed 600mA.
This not required if wires were previously connected to the battery tabs on the
control.
CURRENT
DRAW
30mA
120mA
140mA
35mA
15/180mA ‡
35mA
35/100mA ‡
160mA
Depends on type
of Radio used
(see its
instructions).
– 61 –
NUMBER OF
TOTAL CURRENT
(
device mA x # of units)
DEVICES
=
TOTAL
**
