Check-Out Procedure For Wired Expansion Zones
10 Input Dev:
LP#
AUX WIRED AW: 01
Typical summary display
Zn ZT
RC In
L
10
03 –
03 AW: –
Program Alpha?
0 = No 1 = Yes
0
Enter Zn Num.
(00 = Quit)
11
Enter next zone number ↑
After you have completed installation of all devices, all wired expansion zones
should be checked as follows:
1. Make certain that all devices and sensors connected to the wired expansion
zones are not in a faulted state. Doors and windows with contacts should be
closed, PIRs should be covered (use a cloth to mask them temporarily if
necessary).
2. With all zones intact (including hard-wired zones), the Alpha keypad
connected to the system should display:
If the following is displayed,
DI S ARME D P r e s s
to s how fa ul ts
press the [ ] key to display the faulted zone(s). Restore any faulted zone(s)
as necessary.
Make sure that you have connected a 1000 ohm EOL resistor across
the terminals of unused expansion zones on the 4219 or 4229 module).
When the READY TO ARM message is displayed, you can proceed to the
next step.
– 25 –
At the "INPUT DEVICE" prompt, enter "2" (AUX
Wired) as the input device. The display on the
left will appear.
Press [ ] to continue.
A summary display will appear, showing the
data for the zone that was just programmed.
Note that AW indicates an auxiliary wired (zone
expansion module) zone.
If it is programmed satisfactorily, press [ ] to
display the next prompt.
For all zone types, the next request is to enter
Alpha descriptors for the zones. The entry may
be done now (enter 1) or may be done at a later
time using 82 interactive menu mode (enter 0).
We recommend that the entry of Alpha
descriptors be done later using
mode.
See ALPHA DESCRIPTION PROGRAMMING
section for specific procedure.
If "0" (No) was entered above, the system will
display a prompt for entry of the next wired
expansion zone number. Proceed with the
programming for the next zone, as indicated
previously.
When all wired expansion zones are
programmed satisfactorily, exit 56 mode at the
Enter Zn Num. prompt by pressing: [0] [0] .
Exit the programming mode by keying 99.
Proceed to the check-out procedure that follows.
DI S ARME D
RE ADY TO ARM.
82 menu
(Continued)
