46 8000 Series Reference Manual
Bluetooth Menu > Echo Tests
These echo tests are used for verifying connectivity to make sure the mobile computer is
within coverage. Press [ESC] to stop and exit the test.
In PAN mode, the echo test helps measure the coverage of the range, estimate the number of
APs and the mobile computers needed, and determine the topology of deploying APs.
SPP:
DUN:
HID:
BNEP:
Bluetooth Menu > 4. Echo Tests
1. SPP Master
Serial Port Profile
It is used for ad hoc networking, without going through any access point.
Dial-Up Networking Profile
DUN Modem - It makes use of a Bluetooth modem or mobile phone as a
wireless modem.
DUN GPRS – It makes use of a mobile phone with GPRS functionality and
connects to GPRS AP.
Human Interface Device Profile
It allows the mobile computer being used as a Bluetooth keyboard.
Bluetooth Network Encapsulation Protocol
It is used by Personal Area Networking Profile (PAN) for IP networking
over Bluetooth.
Set the mobile computer as a master device.
1. Pairing with your computer (slave) must be completed first.
2. Run the Echo Test program on your computer. Associated settings include
- Select "RS-232" for interface.
- Use the Bluetooth COM port that has been paired.
- Set Action Mode to "Passive".
3. Start the echo test on both ends. The mobile computer will try to connect
to PC (slave).
