OPERATION OPTIONS

VIDEO LOSS

Screen will display "VLOSS" in the center of display picture, if the video input is not connected properly.

1. LAST RECORD

Play the last recorded piece of video.

2. FULL LIST

List all recorded video on the HDD which sorted by time.

: Manual Recording

: Alarm Recording

: Timer Recording

M : Storage in Master HDD

S : Storage in Slave HDD

NOTE: It will display different color on each record list

mention above.

3. ALARM LIST

List all recorded video triggered by Alarm.

NOTE : If there are no Alarm in the record, the screen will

display "EMPTY".

4. MOTION LIST

List all motion triggered records.

5. TIME SEARCH

Find video recorded on a specific date that is entered.

KEY LOCK

For advanced security, you can "Lock" the buttons on your DVS. Key-Lock prevents other people from using the system.

Press ENTER and MENU at the same time to enable Key Lock.

Press ENTER and MENU at the same time and key in password (Default : 0000), then press "ENTER" to disable Key Lock.

NOTE: To switch to different USER, press "ENTER" + "MENU" buttons to "KEY LOCK" and then enter the different user's

password to UNLOCK.
