CPcam 4 CH Digital Video System User Manual page 13

2. START
Set the time to start the recording.
3. END
Set the time to end the recording.
4. IPS (IMAGES PER SECOND)
NTSC－30、15、8、4、2、1
PAL－25、12、6、3、2、1
5. QUALITY
Select the quality of recording image: BEST, HIGH, NORM and BASE.
6. MODE
There are three recording mode settings :
QUAD-FRAME, QUAD-FIELD, MULTIPLEX.
NOTE: To ensure the best recording quality, we don't suggest
the users switch a different recording mode during
the period of recording.
7. TIMER ENABLE
When TIMER ENABLE is "YES", press "menu" button, you
can see the timer diagram according to your setting.
CAMERA
1. TITLE
Assign a title to each camera. Initially each title is the camera's number.
(Max: 8 characters)
2. ALARM
Select LOW / OFF / HIGH for alarm polarity. The default value is LOW.
ALARM
TITLE
LOW
CAMERA01
OFF
CAMERA02
CAMERA03
HIGH
HIGH
CAMERA04
(CAMERA)
CT
REC BR
ON 15
18
OFF 18 15
OFF 18
15
ON
18 15
12
(TIMER)
DAY START END IPS QLT MODE
DAILY 01:00 22:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
OFF 00:00 00:00 30
TIMER ENABLE : YES
CL HUE
15 18
18
15
18
15
18
15
BEST Q-FR
BEST Q-FI
BEST Q-FI
BEST Q-FR
BEST Q-FR
BEST Q-FR
BEST MUX
BEST Q-FI
(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
MOTION
DISPLAY
REMOTE
USER
SYSTEM
EVENT
