Gateway Tower User Manual page 272

Chapter 13: Upgrading Your Computer
6
Slide the system board toward the front of the case, then up and out of
the case. The system board standoffs slide out of the keyhole slots.
7
Slide the new system board into the keyhole slots and lock it into place
with the thumbscrew.
Important
8
Reconnect the power and data cables using your notes from
more information, see the system board documentation.
9
Install the add-in cards using the instructions in
add-in cards" on page
10
Close the case using the instructions in
262
The new system board must have special standoffs
( pem studs ) mounted on the bottom of the board. If
necessary, use the standoffs from the original
system board.
256.
www.gateway.com
Standoff Keyhole slot
"Adding or replacing
"Closing the case" on page
Step 4. For
247.
