CYBEX Pro+ Service Manual page 67

ITEM QTY. PART NO. DESCRIPTION
105 2 PL-17686 Tab, Bookholder
106 1 HX-16931 Clamp, Cable, 5-16 dia Standard
107 1 AD-16559 PCA, Pro+, Lower Display, English
107 1 AD-16559-Q PCA, Pro+, Lower Display,
International
108 1 SK-17171 PCA, Pro+, Upper Display, English
108 1 AD-18199-Q PCA, Pro+, Upper Display,
International
110 1 AD-19366 PCA, CSAFE Port Board, W-TVS
111 1 EC-17763 PCA Salutron Serial Output
112 1 AW-17707 Cable, CHR to display with ferrite
113 1 AF-17684 Handrail, Weldment
116 2 HX-15499 Grip Handlebar
118 6 HS-10716 Screw 4-40 x 0.38 PNHD Phil
119 4 EH-00472 Wire Tie Ty-23M
120 1 FS-16841 Mount, E-stop Magnet
121 2 HS-16940 Screw, Sems 10-32 x 3/8", PNHD
ext, BL ZN
122 1 FS-16990 Plate, Switch, Power On-Off
123 1 SW-10523 Switch, On-Off
124 12 HS-41187 Screw, 8/16 x 5/16", Plastite
125 17 HS-15706 Screw, 8/16 x .50", PNHD STL BLK
Phil
126 1 HX-17711 Plug, Hole Plastic 7-16 Black
127 1 HX-19040 Clamp, Cable, 3/4" Diameter
128 1 HX-17697 Tape, Double Sided, Die Cut, .062",
Thick
129 1 HX-16842 Magnet, E-stop
130 2 AX-19669 Grip, Heartrate Grip, Top
131 2 AX-19670 Grip, Heartrate Grip, Bottom
132 2 PL-20360 Endcap, Heartrate Grip
133 4 HS-20306 Screw, 6 - 20 X 1.12", PNHD PHIL
134 1 AX-16812 Power Factor Correction Assembly
135 1 AX-21397 Assembly, Deck Stiffener, Pivot, Left
136 1 AX-21396 Assembly, Deck Stiffener, Pivot,
Right
137 2 HS-19108 Screw, 5/16 - 18 X 34", LG, HXHD,
Whiz-lock, GR5
138 1 FM-19439 Shaft, Deck Pivot
139 2 HN-20041 Nut, 1/4 - 20, Propeller, .305" OD
140 2 HW-20044 Washer, Belleville, 15 X 8.2 X
1.0 MM, .5MM Thick
141 2 HS-18358 Bolt, 5/16 - 18 X .1.25", SCHD CAP,
BLK ZN
142 1 DE-19451 Decal, WEEE Symbol
143 2 DE-17714 Decal, Cybex, 13.8 X 2.2"
144 1 DE-16784 Decal, Side Stripe
145 2 DE-17713 Cybex Pro+ Decal for Side
Extrusions
146 2 HN-60064 Nut, Jam 3-8"-16 blk zn
147 1 EC-15004 Ferrite, Clamp-on, .40" ID
200 1 AF-20678 Bracket, SLANT Mount,TV Arm
201 1 CP-20665 Monitor, CYBEX, 15" SECAM/PAL
201 1 CP-20794 Monitor, CYBEX, 15"
202 1 HX-20032 Cap, Domed, Plastic
203 2 PL-20015 Cap, Black
204 3 FT-19980 Tube, Spacer, .375 Dia , .28" Wall
205 1 HS-20036 Screw, 5/16-18 x 1.50", ScHd, Stl,
Zn
206 2 HS-41107 Bolt, 5/16-18 x 1.50", Bh, SS, Bl
207 2 HX-20782 Bushing, T- Type,Rubber, Ring
Mount, Vibration Isolator
208 8 HW-20779 Washer, Flat, 1.44 x .325", SS
209 6 HX-20778 Bushing,Rubber, Ring Mount,
Vibration Isolator
210 1 HW-53018 Washer, 5/16", Split
Cybex Pro+ Treadmill Service Manual
ASTC
ITEM QTY. PART NO.
211 4 HS-20731
212 4 HW-21285
213 4 HW-20214
NS 1 AW-16561
NS 1 AW-16572
NS 1 AW-16578
NS 1 AW-16579
NS 1 AW-16638
NS 1 AW-16639
NS 1 AW-16640
NS 1 AW-16938
NS 1 AW-17163
NS 1 AW-17164
NS 1 AW-17694
NS 1 AW-17694
NS 1 AW-17706
NS 1 AW-17732
NS 1 AW-19117
NS 1 AW-19502
NS 1 AW-19502
NS 1 AW-19523
UK
NS 1 AW-19648
NS 1 AW-20111
NS 1 AX-16273
NS 1 AX-16956
NS 0 AX-17174
NS 0 AX-17175
NS 0 AX-17217
NS 1 CN-17687
NS 1 FT-16278
NS 1 HS-16921
NS 2 HS-16935
NS 1 HX-00438
NS 2 HX-16852
NS 1 LT-03051
NS 1 LT-17718
NS 1 LT-21250
NS 1 LT-17730-X
NS 1 LT-17446
NS 1 SK-17827
NS 1 SK-18554
NOTE: NS = Not Shown
* Language Key
1-German
2-French
3-Spanish
4-English
6-Japanese
7-Swedish
8-Russian
DESCRIPTION
Screw, M4x10 ScHd Stl, Blk
Washer, Lock, M4 Zn
Washer, Flat, M4
Cable, Univ. Tread Display
Jumper, Switch-Filter, White, US
Jumper, Filter-cntl, White
Jumper, Filter-cntl, Black
Power Cord, 230 VAC, 50Hz
Power Cord, 220 VAC, 60Hz
Power Cord, 115 VAC, 60HZ
Jumper, Switch-Filter, Black, US
Jumper, Switch-Filter, Black, Intl.
Jumper, Switch-Filter, White. Intl.
Cable, Audio, 1/4" to 3.5mm, 18"
Cable & Audio Jack 1/4 in to 3.5 mm
Cable, Contact HR Grip
Cable, 4" Ribbon C-SAFE
Cable, 515T / 530T, A/V, I/O
Cable, AV Keypad Extension
Cable, Ribbon, AV Keypad
Extension
Power Cord, 230 VAC, 50Hz, 13A,
Cable, Speed Sensor
Cable E5, RJ45
Clamp Assy, Handrail Ext.
Kit, Install Hardware
Handrail Extension Kit, Left Only -
Complete kit with instructions
Handrail Extension Kit, Right Only
Complete kit with instructions
Handrail Extension Kit, Left and
Right - Complete kit with instructions
Adapter, 1/4" Plug to 1/8" Jack
Handrail Extension, Spacer, Bottom
hardware
Handrail Extension, Bolt, 5/8-11 x
4.75, Bottom hardware
Handrail Extension, Screw, Set 1/2
13 x 1/2", Top Hardware
Allen Wrench, 3/16"
Handrail Extension, Grip
Sign, Facility Safety
Poster, Assembly
Product Registration Sheet
Owner's Manual, Cybex Pro+*
Warranty Sheet, Cybex Pro+, Pink
Kit, Assembly, Contact Heart Rate
Grip, Pair
Brush Kit, Pair, 110 or 220 VDC, w/
spring clips
Service
Page 4-39
