B. Connect these two power cord cables to the power switch:
• The blue cable connects to the top left switch fast-on.
• The brown cable connects to the top right switch fast-on
NOTE: You will connect the ground in step 10D.
C. Connect the line fi lter fast-ons to the power switch.
• The white cable connects to the bottom right switch fast-on.
• The black cable connects to the bottom left switch fast-on
D. With the ground wire through the access hole to the lower control bracket, put the ground
wire terminal on the stud on the lower board bracket.
E. Using a 3/8" nutdriver, secure the one nut and one washer over the ground wire terminal.
F. Using a Phillips screwdriver, secure the switch plate to the treadmill with the I (on)
toward the top.

Upper Display Board

Tools Required
• Phillips screwdriver
• ESD (Electro Static Discharge) grounding strap
1. Disconnect the external power source.
A. Turn the main power switch on the left side to the off (O) position.
B. Unplug the treadmill from the power outlet.
NOTE: The display board is susceptible to damage from a discharge of static electricity. While handling
parts underneath the console cover use an ESD grounding strap. This eliminates the potential
voltage (static) difference between you and the equipment you are working on. Wear an ESD
strap for the rest of this procedure.
2. Remove the console back from the handrail.
NOTE: If you have a cable plugged into the RJ-45 port disconnect it.
A. Using a Phillips screwdriver, remove the nine screws that hold the console back to the console
front.
B. Gently pull off the console back.
