Display Cable - CYBEX Pro+ Service Manual

A. Gently push the CSAFE connector into its port on the display board. See Figure 23.
B. Using a Phillips screwdriver, secure the CSAFE board with the three screws removed
during step 3B. NOTE: Do not overtighten.
5. Secure the console back.
A. While being sure not to pinch any cables, use a Phillips screwdriver to secure the nine screws
that hold the console back to the console front.

Display Cable

Tools Required
• Phillips screwdriver
• ESD (Electro Static Discharge) grounding strap
• Wire cutters
! WARNING: Disconnect the power cord before beginning this procedure. Keep wet items away
from inside parts of the treadmill. Electrical shock could occur even if the treadmill is
unplugged. Do not touch components on the lower board. A charge can remain after
unplugging the power cord and turning off the treadmill.
1. Disconnect the external power source.
A. Turn the main power switch on the left side to the off (O) position.
B. Unplug the treadmill from the power outlet.
NOTE: The display board is susceptible to damage from a discharge of static electricity. While handling
parts underneath the console cover use an ESD grounding strap. This eliminates the potential
voltage (static) difference between you and the equipment you are working on. Wear an ESD
strap for the rest of this procedure.
2. Remove the console back.
A. Using a Phillips screwdriver, remove the nine screws that hold the console back to the console
front.
B. Gently pull off the console back.
3. Remove the motor cover.
A. Using a Phillips screwdriver, loosen three screws on each motor cover side (left and right). See
Figure 2.
B. Lift the motor cover center up and off the treadmill. The screws will stay in place. See Figure 2.
4. Remove the left junction covers.
A. Using a Phillips screwdriver, remove the three screws that hold the left junction
covers in place.
5. Remove the display cable.
! WARNING: Do not touch components on the lower board. A charge can remain after
unplugging the power cord and turning off the treadmill.
Cybex Pro+ Treadmill Service Manual
Service
Page 4-33
