MEITRACK® OBD Vehicle Tracker
Shenzhen Meiligao Electronics Co., Ltd.
Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.
File Name
MEITRACK TC68 User Guide
Project
TC68
Sub Project
User Guide
Revision
V1.5
TC68
User Guide V1.3
Creator
Creation Date
Update Date
Page
Confidential
External Documentation
Renny Lee
2012-07-13
2012-11-28
1 of 26
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC68 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MeiTrack TC68

Summary of Contents for MeiTrack TC68

  • Page 1 File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 1 of 26 Revision V1.5 Confidential External Documentation MEITRACK® OBD Vehicle Tracker TC68 User Guide V1.3 Shenzhen Meiligao Electronics Co., Ltd.

  • Page 2: Table Of Contents

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 2 of 26 Revision V1.5 Confidential External Documentation Contents Notice ..................................3 1.1 Usage Information ............................... 3 1.2 Product Accessory ............................... 3 Product Function and Specifications ........................

  • Page 3: Notice

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 3 of 26 Revision V1.5 Confidential External Documentation 1. Notice 1.1 Usage Information 〇 This product is a wireless communication terminal, please turn off the device before getting into the oil depot, places of dangerous goods, restricted area.

  • Page 4: Product Function And Specifications

    2. Product Function and Specifications 2.1 Introduction TC68 is a GPS vehicle tracker with OBD II (On-Board Diagnostics II) functions, which can achieve vehicle positioning, tracking and anti-theft, vehicle examination and fault diagnosis. With standard OBD II plug. TC68 can be easily and quickly installed. Built-in battery provides TC68 with sufficient backup power. When TC68 is being removed, it will send alert notification to mobile devices or servers.

  • Page 5: Alarms

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 5 of 26 Revision V1.5 Confidential External Documentation Timing Tracking Set the time interval of timing tracking, the terminal will be in accordance with the preset time reported location information at interval to the platform or mobile phone.
  • Page 6 GPS Tracking When the GPS tacks the position, the terminal will record car running track preset time. Track Recorder Function record can be read by the software of the <Meitrack Manager>, enable to store a total of 130,000records. GPS&GSM When the GPS cannot receive signals, the GSM base station will use the secondary Tracking positioning, to ensure that any time can be found in the vehicle location.

  • Page 7: Exterior

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 7 of 26 Revision V1.5 Confidential External Documentation 3. Exterior 1. TF Card Slot 2. SIM Card Slot...

  • Page 8: Quick Operation Instruction

    Remove the cover of TF card and insert TF card as picture (chip down), then recover it. 4.2 Charge the Battery Please charge TC68 for at least 3 hours by the USB cable while the first using. To short the charging time, please turn off TC68 while charging.

  • Page 9: Gps Tracking

    Revision V1.5 Confidential External Documentation Press and hold the Power On/Off button for 3~5 seconds to turn on/off TC68. Once insert TC68 into OBD II Port in the vehicle, the buzzer will alarm BI . GPS LED (Blue) Status Description Charging Flashing (every 5 secs.)

  • Page 10: Sos- A71

    Password is 4 digits only and defaulted as 0000. You can change the password by Parameter Editor and SMS command. TC68 will only accept commands from a user with the correct password and report SMS report to the user. If preauthorized phone number was set, only this phone number can receive SMS reports.

  • Page 11: Listening-In (Voice Monitoring) - A72

    TC68 automatic reply SMS: IMEI,A71,OK Prompts successful, successfully set SOS emergency communications number. When you press the SOS emergency button, TC68 will dial 3 preauthorized phone numbers. It will stop dialing when one number answers. Note: the default value is empty. The function numbers should be added “,” to avoid setting failure. The last function number doesn’t need a “,”.

  • Page 12: Time Zone - B35

    IMEI,B35,OK Set the time zone successfully. Note: this value is your TC68’s IMEI number. The device will send this data automatically and these numbers don’t represent anything significant to the functionality of the tracker. Below the same applies. 4.4.5 More Settings You can configure TC68 by mobile phone or by computer using the Meitrack Manager to Setting Multiple Software.
  • Page 13 Confidential External Documentation Run MEITRACK Manager.exe , turn on the device and connect it to the computer via USB, the software will automatically indentify the port number and read out all parameter as follow: Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.
  • Page 14 File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 14 of 26 Revision V1.5 Confidential External Documentation Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.

  • Page 15: Sms Tracking

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 15 of 26 Revision V1.5 Confidential External Documentation 4.5.1 SMS Tracking SMS Tracking Select Column 2: Item Description...
  • Page 16 File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 16 of 26 Revision V1.5 Confidential External Documentation Incoming Call Report Location Report location via SMS after the incoming call is hung up.

  • Page 17: Grps Tracking And Buzzer Reminding Configuration

    File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 17 of 26 Revision V1.5 Confidential External Documentation interval. SMS Interval Time: Report location by SMS time interval.

  • Page 18: Fault Record

    Steps: Click Read Data icon, TC68 will record the previous fault code from the car to the Meitrack Manager. Select TC68 and the period, click Search icon. It will show out all fault records of this period. If no data, it means there is no fault of this car.
  • Page 19 Click “Freeze Frame “as follow, you will find a list of data string of the fault, which will help Maintenance technician to analyzed & solved the fault exactly. If there are many fault code, TC68 will record the most advanced freeze frame, such as: Security System Freeze Frame>Dynamical System>Comfort System Copyright ©...
  • Page 20 4S shops charge too much repaired fee to the car owner. Please refer to MEITRACK SMS Protocol and MEITRACK GPRS Protocol, if you want to know more GPRS Setting. Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.

  • Page 21: Platform Tracking

    5. TC68 Installation TC68 is a plug and play (PNP) model, simple and without wires connection. When plug the TC68 to the car connector, it will sound BI one time, and all LED will begin blinking, it means plug successfully.

  • Page 22: Plug Car Connector Directly

    When install the extension cord, please plug the male connector to Car’s OBDII socket, plug the female connector to TC68 socket. Affixed two small suede Velcro to the labeled TC68 surface and the connected surface of extension cord. Plug the male connector of the extension cord to the car OBDII connector.
  • Page 23 File Name MEITRACK TC68 User Guide Creator Renny Lee Project TC68 Creation Date 2012-07-13 Update Date 2012-11-28 Sub Project User Guide Page 23 of 26 Revision V1.5 Confidential External Documentation Plug car’s OBDII socket Plug TC68 socket GPS Antenna is under the no-lable surface, please face it ypto the skype when install.
  • Page 24 24 of 26 Revision V1.5 Confidential External Documentation Suede Velcro affixed on the TC68 mark side, then fix its lateral side on the car Small Velcro Medium Velcro Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved. -24-...

  • Page 25: Applicable Type Of Vehicles

    Confidential External Documentation 6. Applicable Type of Vehicles TC68 is suitable for all vehicles with OBDII/EOBD port. The following are part of the type of the vehicles : ◈ American gasoline vehicles sold after 1996; Chinese vehicles sold after 2003.

  • Page 26: Copyright And Disclaimer

    Meiligao (MEITRACK), or transmitted in any form, either electronically or mechanically, including photocopying and recording. In no event shall Meiligao (MEITRACK) be liable for direct, indirect, special, incidental, or consequential damages (including but not limited to economic loss, personal injury, and loss of asset and property) arising out of the use or inability or illegality to use the product or documentation.
