INSTALLATION
continued
Methods For Attaching Mounting
Bracket To Wall
Only use last hole on each end
of mounting bracket to attach
bracket to wall. These two holes
are 16 inches apart from their
centers. Attach mounting bracket to
wall only in one of two ways:
1. Attaching to wall stud
2. Attaching to wall anchor
Note: Wall anchors, mounting screws
are in hardware package. The hard-
ware package is provided with
heater.
Attaching to Wall Stud: This method
provides the strongest
mounting screws through mounting
bracket and into wall studs.
Attaching to Wall Anchor: This
m et ho d allow s you
mounting bracket to hollow walls
(wall areas between studs) or to
solid walls (concrete or masonry).
Decide which method
suits your needs. Either method
will provide a secure hold for the
mounting bracket.
Marking Screw Locations
1. Tape mounting bracket to wall
where heater will be located.
Make sure mounting bracket is
level.
WARNING: Maintain the
minimum clearances shown in
Figure 6. If you can, provide greater
clearances from floor, ceiling, and
joining wall.
2. Mark sc rew loc at io ns
wall. (see Figure 6)
Note: Only mark last hole on
each end of mounting bracket.
Insert mounting screws through
these holes only.
3. Remove tape and mounting
bracket from wall.
Model MN200EBC MN200EHBC
Model MN300EBC MN300EHBC
Figure 6 - Mounting Bracket
hold. Insert
Clearances
Attaching to Wall Stud Method
For attaching mounting bracket to
wall studs
1. Drill holes at marked locations
to att ac h
using 9/64
2. Place mounting bracket onto
wall. Line up last hole on each
end of bracket with holes drilled
better
in wall.
3. Insert mounting screws through
bracket and into wall studs.
4. Tighten screws until mounting
bracket is firmly fastened to
wall studs.
Attaching to Wall Anchor
Method
For attaching mounting bracket to
hollow walls (wall areas between
studs) or solid walls (concrete or
masonry)
1. Drill holes at marked locations
using 5/16
walls (concrete or masonry), drill
at least 1
on
2. Fold wall anchor as shown in
Figure 7 below.
Figure 7- Folding Anchor
Only Insert Mounting
Screws Through Last
Hole On Each End
Floor
Only Insert Mounting
Screws Through Last
Hole On Each End
Floor
"
drill bit.
"
drill bit. For solid
"
deep.
8
3. Insert wall anchor (wings
into hole. Tap anchor flush to
wall.
4. For thin walls (1/2" or less),
insert red key into wall anchor.
Push red key to "pop" open an-
chor wings (see Figure 8).
IMPORTANT: Do not ham-
mer key! For thick walls (over 1/
"
2 t h i c k ) o r s o li d
do not pop open wings.
Figure 8 - Popping Open Anchor
Wing For Thin Walls
5. Place mounting bracket onto
wall. Line up last hole on
each end of bracket with wall
anchors.
6. Insert mounting screws through
bracket and into wall anchors.
7. Tighten screws until mounting
bracket is firmly fastened to wall.
Placing Heater on Mounting
Bracket
1. Locate two horizontal slots on
back panel of heater (see
Figure 9).
2. Place heater onto mounting
bracket. Slide horizontal slots
o n t o s t a n d - o u t
mounting bracket.
Figure 9 - Mounting Heater Onto
Mounting Bracket
first)
w all s,
t a b s o n
