ELRO DVR158S User Manual
  1. Manuals
  2. Brands
  3. ELRO Manuals
  4. Security System
  5. DVR158S
  6. User manual

ELRO DVR158S User Manual

Camera security dvr system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
- 0 -
Directory
1. DVR FEATURE .................................................................................................................................... 3
2. OUTLOOK ............................................................................................................................................ 3
........................................................................................................................................ 3
2.2 F
P
................................................................................................................................... 4
RONT
ANEL
2.3 R
P
..................................................................................................................................... 6
EAR
ANEL
2.4 L
P
................................................................................................................................ 7
ATERAL
ANEL
2.5 R
C
...................................................................................................................... 7
EMOTE
ONTROLLER
3. DVR INSTALLATION ........................................................................................................................... 7
3.1 I
H
D
........................................................................................................................... 7
NSTALL
ARD
ISK
3.2 C
C
M
..................................................................................................... 8
ONNECT
AMERA AND
ONITOR
3.3 S
C
...................................................................................................................... 8
ENSOR
ONNECTION
3.4 A
C
......................................................................................................................... 8
LARM
ONNECTION
3.5 M
C
........................................................................................................................ 9
OUSE
ONNECTION
3.6 C
P
C
................................................................................................................... 9
ONNECT
OWER
ORD
4. DVR SYSTEM BOOT ........................................................................................................................... 9
5. DVR SETUP ....................................................................................................................................... 10
5.1 M
D
.......................................................................................................................... 10
ENU
IRECTORY
5.2 M
M
..................................................................................................................................... 11
AIN
ENU
5.3 C
.......................................................................................................................................... 11
AMERA
......................................................................................................................................... 12
5.4.1 Record Framerate .................................................................................................................. 12
5.4.2 Record Quality ....................................................................................................................... 13
5.4.3 Record Schedule.................................................................................................................... 13
............................................................................................................................................ 14
5.5.1 Alarm Duration ....................................................................................................................... 14
5.5.2 Buzzer Duration ..................................................................................................................... 14
5.5.3 Event Rec Duration ................................................................................................................ 15
5.5.4 Sensor .................................................................................................................................... 15
5.5.5 Motion..................................................................................................................................... 15
............................................................................................................................................. 16
.......................................................................................................................................... 16
5.7.1 Password Setup ..................................................................................................................... 17
5.7.2 Hard Disk Setup ..................................................................................................................... 17
5.7.3 Time Setup ............................................................................................................................. 18
5.7.4 Event List ............................................................................................................................... 18
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR158S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ELRO DVR158S

Summary of Contents for ELRO DVR158S

  • Page 1: Table Of Contents

    Directory 1. DVR FEATURE ............................ 3 2. OUTLOOK ............................3 2.1 T ............................3 OP PANEL 2.2 F ........................... 4 RONT ANEL 2.3 R ............................. 6 ANEL 2.4 L ..........................7 ATERAL ANEL 2.5 R ........................7 EMOTE ONTROLLER 3. DVR INSTALLATION ........................... 7 3.1 I ...........................

  • Page 2: Dvr Feature

    5.7.5 Network Settings ........................19 1. DVR Feature 5.7.6 PTZ Setup ..........................20 5.7.7 Screen Adjustment ......................... 22 8 Channel BNC Camera Input. 5.7.8 Key lock ..........................22 1 Channel BNC Monitor Output. 5.7.9 Border............................. 22 Support Network: Static, DHCP. 5.7.10 Auto sequence ........................

  • Page 7: Record

    DVR system can display eight cameras and videos in frames. one picture. User can configure which camera to display. If you make the record frame rate off, the channel won’t record. If the order of “Display” for one channel is OFF, system Press button [SEL/EDIT] or hold a left mouse click button to click icon “►”...

  • Page 8: Alarm

    5.5.3 Event Rec Duration “ ”: Motion Triggered. The time period with a green bar for built-in motion recording(MD). (See also the following chapter “MOTION DETECTION”) It sets the record time of duration (in seconds) after motion recording is activated. “...

  • Page 9: Audio

    5.7.1 Password Setup The keypad and mouse control instructions are below. [Using DVR Front panel or remote control button] Press 「SEL/EDIT」to enter “Password Setup”. Press [SEL/EDIT] once to pitch on the area, press [SEL/EDIT] twice to cancel the area. Press 「SEL」to input value, and then move the [FULL] –...

  • Page 11: Ptz Setup

    「REW」 「Fwd」:Zoom. bar the order of “Network、IP Address、Port and DVR Name” can be modified. Press「 Up」and 「 Down」to move prompt. Press 「 「Pause」 「Play」: Focus. Select」to enter into each submenu. Press「 Select」or 「REC」to modify value. Mouse function: Left Mouse: Click the icon “►” or “◄” to adjust value. Right Mouse: Previous.

  • Page 12: Screen Adjustment

    5.8 Search 5.7.7 Screen Adjustment Press the button 「 SEL」 to enter “ Time Search”, on Press「Select」button accessing to “ Screen Adjustment”. You can move the entire video screen up, the menu user can look over start time and end down, left, and right using this option.

  • Page 15: Network

    icon. Find “Local Area Connection” and Right Click and select “Properties”. 9.4.2 Program Interface Find “Internet Protocol [TCP/IP]” and click “Properties”. Select “Use the following IP address” and “Use the following DNS server address”, and then input IP value. A: Run Vxviewer8Ch. Finally, Click “OK”...

  • Page 18: Connect Pc To Dvr - Ie Browser

    9.5. Connect PC to DVR — IE Browser At first please turn all the Active X option ON at IE Internet safety setup. Select menu setup to enable the Active X option. Network module use Active X applet to display remote image. Any web browser with Active X support can connect to DVR.

  • Page 19: Specification

    10. Specification ITEM DESCRIPTION Video Format NTSC / PAL Camera Input Channel 8 channel Composite BNC Video Output Channel 1 channel Composite BNC NTSC：Max 60 fps (Total)； 1fps～Max. 30 frames/s (Each Channel)； Recording Speed PAL：Max.50 fps (Total)； 1fps～Max. 25 frames/s (Each Channel) Time schedule, Motion detection, Sensor activated, Motion detection &...

  • Page 20: Appendix

    Audio 1CH RCA input, 1CH RCA output to monitor 6. PS/2 Mouse (Optional) 1pcs Network IE View YES, RJ45 7. Batteries of Remote Control 1pcs USB for media Backup and software upgrade Power Input 100-240VAC/DC 12V，5A（Adapter supplying） Dimension Length 312mm * Width 360mm * Height 52mm(Not including bracket) 11.

Table of Contents
