Generac Power Systems 04389-0 Installation And Owner's Manual page 54

21
20
25
24
10
28
12
11
28
ITEM PART NO. QTY.
1 0C5322 1
2 0C5765 1
3 0C4647 1
4 0C4680 1
5 0C6070 1
6 022985 4
7 022264 4
8 075475 4
9 0C5760D 2
0C5760A 1
10 0C6606 2*
11 097934 2*
12 0C4645 2*
13 0C5761 2*
14 0C5968 2*
15 0C6066 2*
16 0C5759 2*
17 0C5764 2
0C5764A 1
18 070728 4
070728 2
52 Generac Power Systems, Inc.
®
Section 7 — Exploded Views and Parts Lists
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
Gas Regulator – Drawing No. 0D1259-A
10
22
23
19
28
12
28
26
15
17
9
DESCRIPTION
CASTING, TWIN REGULATOR HOUSING
SOLENOID, TWIN REGULATOR
GASKET , SOLENOID
PLUNGER, LP REGULATOR ASSEMBLY
SPRING-SOLENOID, PLUNGER
WASHER, FLAT #6
WASHER, LOCK M4
SCREW PPHM M4-0.7 X 10
JET, GN 990 ENGINE LP (12KW / 15KW)
JET, GN 410 ENGINE LP (7KW)
BARBED STRAIGHT 1/2NPT x 1/2
O-RING, CHECK VALVE
ADJUSTER SCREW, TWIN REGULATOR
LEVER, REGULATOR
SUPPORT, INLET SEAL
SEAL, INLET
PIN, PIVOT ARM
SPRING, REGULATOR (12KW / 15KW)
SPRING, REGULATOR (7KW)
SCREW, PFIHM M3-0.5 x 5
(12KW / 15KW)
SCREW, PFIHM M3-0.5 x 5 (7KW)
8
7
2
6
5
4
3
1
26
11
17
27
29
18
14
16
13
ITEM PART NO.
19 0C6069
20 0C5762
21 045764
045764
22 0C6731
23 0C6067
24 0C4706
25 0C6068
26 0C4643A
27 026073
28 0A4032
29 0D3308
0D3308
30 0C4643
* A QUANTITY OF 1 IS TO BE USED ON 7KW HOME STANDBY
16 29
18
15
14
19
13
23
24
22
QTY. DESCRIPTION
2* GASKET, DIAPHRAGM
2* COVER, TWIN REGULATOR
16 SCREW, TAPTITE M4X8 BP
(12KW / 15KW)
8 SCREW, TAPTITE M4X8 BP (7KW)
2* RIVET, POP .118 X .125
2* SUPPORT, DIAPHRAGM
2* DIAPHRAGM, TWIN REGULATOR/
SOLENOID
2* CAP, DIAPHRAGM SUPPORT
2* INLET, TWIN REGULATOR 11.11 DIA.
1 PLUG, STANDARD PIPE 1/8 STEEL
SQUARE HEAD
4* PIN, LIMITED ADJUSTMENT
4 WASHER, FLAT M3 X 10mm O.D.
(12KW / 15KW)
2 WASHER, FLAT M3 X 10mm O.D. (7KW)
1 INLET, TWIN REGULATOR NO HOLE -
NOT SHOWN (7KW)
20
25
21
