Generac Power Systems 04389-0 Installation And Owner's Manual page 45

ITEM PART NO. QTY. DESCRIPTION
73 0C5136A 2
74 0C3024 1
75 0C3040 1
76 0C8127 1
77 0C7720 1
78 0D2595 4
79 0D4417 4
80 0C3025 1
81 0D3083 1
82 0C7292 1
83 070185 1
84 075281 1
85 0C1085 2
86 043182 2
87 035461A 2
88 040173 4
89 0C9806 2
90 0C3026 1
91 0C9764 4
92 0C3043 2
93 0C7694 1
94 0C7693 1
95 0C3041 2
96 070008 4
97 070006 4
98 040976 4
99 0C3016A 1
100 0C1069 23
101 085011 1
102 0C3725B 1
103 0C3031 1
104 0C3032 1
105 0A5992 2
106 051754 2
107 0C3033 1
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
GT-990/760 Engine – Drawing No. 0D3415-A Part 2
KNOB, AIR CLEANER
COVER, AIRBOX NG/LP
PRE-CLEANER,
ELEMENT, AIR CLEANER
MIXER / AIRBOX, ASSEMBLY
SCREW SHOULDER (8MM) M6-1.0 X 18
WASHER,RUBBER 1/4" X 1/8" THICK
SWITCH, OIL PRESS
ASSEMBLY, OIL DRAIN HOSE
NIPPLE, 3/4"-16 UNF
FILTER, OIL D 69 X 64 LONG
SWITCH, THERMAL 284F
SCREW PPHM M3-0.5 X 8
WASHER LOCK M3
BARBED STR 1/4NPT X 3/8
WITH VIBRA SEAL
CLAMP HOSE #5.5 .62 - .62
HOSE, 3/8" I.D. X 6" LONG
COOLER, OIL
PLASTITE,1/4-15 X 3/4
GASKET, MANIFOLD / PORT
MANIFOLD INTAKE CYLINDER 2
MANIFOLD INTAKE CYLINDER 1
SLEEVE, RUBBER
WASHER FLAT M8 SS
WASHER LOCK M8 SSTL
SCREW SHC M8-1.25 X 20 G12.9
PLATE, BACKING GT990 WITH OIL COOL
SCREW TAPTITE M6-1.0X8
YELLOW CHROME
INSULATOR ASSEMBLY IGNITION
FLYWHEEL ASSEMBLY
FAN, NYLON
PLATE, FAN
WASHER SHAKEPROOF INT M8 SS
SCREW HHC M8-1.25 X 12 G8.8
WASHER, M5
Section 7 — Exploded Views and Parts Lists
ITEM PART NO. QTY. DESCRIPTION
108 0C3034
109 0C8549
110 0C3022A
111 0D1131
112 045756
113 0C9763
114 0C3036
115 0C8558
116 0C8564
117 0C3018
118 0C3019
119 0D1142A
120 0D1143
121 066849B
122 0C3053
123 0C3052
124 022097
125 092079
126 0C3017
127 0D4529
128 022129
129 061906
130 082774
131 052859
132 0C8468
133 0C3048
134 0D3754
135 0D3742
136 0C8482
137 0D2576
138 033469
139 0D3743
140 0D3705
141 0C2993
1 NUT,HEX M24
1 SNORKEL, AIR INTAKE
1 HOUSING, BLOWER NG COOLER
1 GUARD, FAN
4 SCREW TAPTITE M6-1X10
YELLOW CHROME
4 NUT, GROMMET 1/4 PLUG
1 HOSE, BREATHER
1 CLAMP, MANIFOLD
1 PLASTITE,#12-16X 3/4
1 WRAPPER, UPPER CYLINDER 1
1 WRAPPER, LOWER CYLINDER 1
1 WRAPPER, LOWER CYLINDER 2
1 WRAPPER, UPPER CYLINDER 2
2 SCREW TAPTITE M5-0.8 X 8 BP
1 ASSEMBLY, GROUND WIRE
2 ASSEMBLY, IGNITION COIL
4 WASHER LOCK M6-1/4
4 SCREW TAPTITE M6-1.0 X 25 BP
1 STARTER
2 SPARKPLUG
2 WASHER LOCK M8-5/16
2 SCREW HHC M8-1.25 X 85 G8.8
1 KEY, WOODRFF 4 X 19D
1 NUT HEX LOCK M10-1.50
1 SPRING, ANTI-LASH
1 ROD, GOVERNOR CONTROL
1 ASSEMBLY, GOVERNOR LEVER
1 SPRING, GOVERNOR
1 ASSEMBLY, GOVERNOR ADJUSTER
1 SCREW SHC M10-1.5 X 70 G10.9
1 SPACER .22 X .37 X .25 CAD PLT
1 SPRING, GOVERNOR IDLE
1 ASSEMBLY, GOVERNOR ADJUSTER
BRACKET
1 SEAL, GOVERNOR SHAFT (NOT SHOWN)
Generac Power Systems, Inc. 43
®
