Generac Power Systems 04389-0 Installation And Owner's Manual page 43

ITEM PART NO. QTY. DESCRIPTION
1 0C5729 1
2 0C3008 1
3 090388 8
4 0C5372 1
5 0C3005 1
6 0C3003 3
7 0C2231 1
8 071983 4
9 0C2981 1
10 045761A 4
11 0C5848 2
12 021533 2
13 071980 2
14 0D4041 1
15 0C2983 1
16 0C2985 1
17 0D4042 1
18 0A7811 1
19 0C2977 1
20 0C5943 1
21 0D4040E 1
21 0D4122E 1
22 0C2969 2
22 0D3105 1
23 0D2157 2
24 0C5313 1
25 0D4123 1
26 078699E 2
27 0C3011 2
28 0C3009 2
29 0C3010 2
30 093873 2
31 0C5315 1
32 0C5998 1
33 0D1667 1
34 0C2991 2
35 0C2988 1
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
GT-990/760 Engine – Drawing No. 0D3415-A Part 1
ASSEMBLY, CRANKCASE HOUSING
WITH SLEEVE
SEAL, 38 I.D. CRANKSHAFT
SCREW, TAPTITE M6-1.0 X 12 BP
ASSEMBLY, BREATHER
GASKET, BREATHER COVER
SEPARATOR, OIL BREATHER
ASSEMBLY, HEAD #1 G&S
RETAINER, PISTON PIN 20
ROCKER, COVER NO OIL FILL
STUD M8-1.25/10MM X 30 G5 ZINC
PISTON, HC
SET, PISTON RING 90MM
PIN PISTON D20
ASSEMBLY, CAMSHAFT & GEAR
SHAFT, GOVERNOR
ROLLER BEARING, GOVERNOR
ASSEMBLY,GOVERNOR GEAR
SPOOL, GOVERNOR MACHINED
GASKET, CRANK CASE
SEAL, OIL PASSAGE
ASSEMBLY, CRANKSHAFT HORIZONTAL
DIRECT DRIVE (GT-990)
ASSEMBLY, CRANKSHAFT AND GEAR HOR-
IZONTAL DIRECT DRIVE (GT-760)
ASSEMBLY, CONNECTING ROD (GT-990)
ASSEMBLY, CONNECTING ROD (GT-760)
SCREW SHC M6-1.0 X 50 G8.8
SCREEN, OIL PICKUP
ASSEMBLY, OIL PUMP
SLEEVE, SEAMED DOWEL 10 DIA.
COVER, OIL RELIEF
SPRING, OIL RELIEF
BALL, 1/2D OIL RELIEF
WASHER, LOCK RIB M6
GEROTOR, OUTER
CLAMP, OIL TUBE
ARM, GOVERNOR
E-RING, GOVERNOR ARM
THRUST WASHER, GOVERNOR
Section 7 — Exploded Views and Parts Lists
ITEM PART NO. QTY. DESCRIPTION
36 0C2992
37 0C3971C
38 0C5305
39 0C3027
40 0C3007
41 0C5731
42 0C3006
43 0C8566
44 093064
45 0C8808
46 0C2982
47 0C2979
48 086515
49 0D2274
50 0D3867
51 078672
52 0C5371
53 072694
54 083907
55 0D3998
56 0C2235
57 0C2976
58 086516
59 0C2229
60 083897
61 0C2231A
62 088396C
63 0C2978
64 043790A
65 0D4010
66 0D4011
67 0D4012
68 0D4013
69 0D4014
70 0D4014A
71 0D4015
72 0D4016
1 BUSHING, GOVERNOR LOWER
1 ASSEMBLY, DIPSTICK WITH HANDLE
1 TUBE, DIPSTICK
1 O-RING, OIL CLR
1 SEAL, 42 I.D. CRANKSHAFT
1 ASSEMBLY, HOUSING COVER
WITH SLEEVE
9 SCREW, HHFC M10-1.5 X 55
8 SCREW HHFC M6-1.0 X 20
1 ASSEMBLY, OIL FILL CAP
2 HOOK, LIFTING
1 ROCKER, COVER WITH OIL FILL
2 GASKET, VALVE COVER
8 KEEPER, VALVE SPRING
4 RETAINER, VALVE SPRING
4 SPRING, VALVE
2 SEAL, VALVE STEM D7
4 WASHER, VALVE SPRING
4 STUD, D20 PIVOT BALL
4 ARM, SOLID ROCKER
4 NUT, HEX M8-1.0 G8 YELLOW CHROM
2 PLATE, PUSH ROD GUIDE
12 SCREW HHFC M8-1.25 X 65
2 VALVE, EXHAUST
2 VALVE, INTAKE
4 TAPPET, SOLID
1 ASSEMBLY, HEAD #2 G&S
4 PUSHROD, 139.6 VERTICAL
2 GASKET, HEAD
1 BARBED ELBOW 90 3/8NPT X 3/8 L0CKTITE
1 KIT GASKET
1 KIT-PISTON RINGS
1 KIT BREATHER ASSEMBLY
1 KIT GOVERNOR ASSEMBLY
1 KIT HEAD ASSEMBLY CYLINDER 1
1 KIT HEAD ASSEMBLY CYLINDER 2
1 KIT OIL RELIEF
1 KIT GEAR COVER
