- Page 50 C2632 BASE, MOUNTING 70936 ISOLATOR-VIBRATION 70936C ISOLATOR, VIBRATION 39253 CAPSCREW, HEX HEAD-M8-1.25 x 20MM 22145 FLAT WASHER-M8 22129 LOCK WASHER-M8 45771 NUT, HEX-M8-1.25 71956 WASHER, VIBRATION ISOLATOR 51730 CAPSCREW, HEX HEAD-M8-1.25 x 60MM 57821 CAPSCREW, HEX HEAD-M8-1.25 x 40MM 21991 STRAP, GROUNDING 27482 WASHER-STAR 5/16”...
- Page 52 097575 BRACE SIDE W/DOORS 0A3769 DOOR WELDMENT 0A3768 DOOR COMPARTMENT REAR 1.6L 0A5314 TOP ENCLOSURE 1.5L 067042 KEY SQ 1/2 X 3-3/4 STEEL 022264 WASHER LOCK #8-M4 067035 SCREW PPHM #8-32 X 5/16 082570 PLUG PLASTIC 4 IN BUTTON 0A7215 SCREW SW 1/4-20 X 5/8 W/WASHER 032990 BUMPER...
- Page 54 0C2632 WELDMENT MOUNTING BASE 075580 FLANGE FUEL INLET 026915 NIPPLE CLOSE 3/4 X 1.375 039253 SCREW HHC-M8-1.25 X 20 022145 WASHER FLAT 5/16 ZINC 022129 WASHER LOCK M8-5/16 045771 NUT HEX M8-1.25 G8 YEL CHR 0A2666 SOLENOID GAS FUEL 046747 BUSHING REDUCER 3/4 TO 3/8 0C3714 ASSY HOSE NG/LPV.31"...
- Page 56 0A4531 ENGINE-1.5L 075614 FAN ENG PUSHER 6/380 035685 CLAMP HOSE #28 1.32 - 2.25 0A2628 PULLEY - FAN 95 DIA 075546A PIPE-FLEX EXHAUST 0A5275 V-BELT 3/8 X 32-1/8 1.5L 0A45310258 GASKET-EXHAUST MANIFOLD 0A5586 V-BELT 3/8 X 28.9 1.5L 0A4355 MANIFOLD-EXHAUST 0A4814 SPACER PULLEY 0A6699...
- Page 58 098290 ASM MOTOR STEPPER 098941A HOUSING GOVERNOR CONNECTOR 098958A CONNECTOR INTERFACE ASSEMBLY 098942A COVER CONNECTOR HOUSING 098225 SCREW FHM #2 X 5/8 SELF TAP 043146 SCREW HHC M6-1.0 X 10 G8.8 022097 WASHER LOCK M6-1/4 064526 SCREW TAP HWH #6-25 X 3/8 ZINC 098783 LEVER STEPPER MOTOR 037398...
- Page 60 020689 MUFFLER W/RAIN SHLD 060366 MUFFLR STRAP 6IN DIA 059933 ELBOW 90 DEG 2 NPT 080761 NIPPLE TOE 2 NPT X 4.5 BLK IRON 059939 RAIN CAP 2.37 I.D. 075546A PIPE FLEX EXHAUST 036434 BOLT U 5/16-18 X 2.09 022259 NUT HEX 5/16-18 STEEL 022129 WASHER LOCK M8-5/16...
- Page 62 098671 ASSY ROTOR 10KW 098681 ASSY ROTOR 15KW 098675 ASSY ROTOR 20KW 098936 ASSY ROTOR 25KW 0A5336A HOUSING BLOWER 0A1659 SCREEN AIR OUTLET 071912 SCREW PPHM M5-0.8 X 8 SS 049226 WASHER LOCK M5 051713 WASHER FLAT M5 022129 WASHER LOCK M8-5/16 098672 ASSY STATOR 10KW A 098673...
