Section 6 — Electrical Data
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
Wiring Diagram – 7 kW – Drawing No. 0D5700-B
28 Generac ® Power Systems, Inc.
DIAGRAM KEY
BA - BRUSH ASSEMBLY
BCR - BATTERY CHARGE RELAY
CB1 - MAIN OUTPUT BREAKER
CB2 - CIRCUIT BREAKER, ALTERNATOR EXCITATION
D - DIODE
DSW - PCB MOUNTED DIP SWITCH
FS - FUEL SOLENOID
F1 - FUSE 15 AMP
F2 - FUSE 5 AMP
GRD - CONTROL PANEL GROUND
HTO - HIGH OIL TEMPERATURE SWITCH
HM - HOUR METER
IC - INLINE CONNECTOR
ICT - INTERCONNECTION TERMINALS
IM - IGNITION MODULE
LOP - LOW OIL PRESSURE SWITCH
RAR - REMOTE ALARM RELAY
SP - SPARK PLUG
SW1 - AUTO / OFF / MANUAL SWITCH
SW2 - SET EXERCISE SWITCH
SM - STARTER MOTOR
TB - INSULATED TERMINAL BLOCK
TX - TRANSFORMER, 16 Vac 56 VA & 16 Vac 1 VA (DUAL SEC.)
SP
IM
HTO
LOP
BLACK
- +
12V
BATTERY
CUSTOMER SUPPLIED
ENGINE WIRING
IC
D
85
IC
86
IC
13
RED
SM
3
2
1
14
0
FS
0
14
0
14
0 6
18 5
85
4
86
3
2
13
0
1
C1
18
56
56
86
0
56
85
SS
PRINTED CIRCUIT BOARD
ON
16
ON - INDICATES
1 - 20 Vac Sense Transformer
2 - Remote Not Auto
3 - 50 Hz Operation
4 - SPARE
BATTERY
CHARGER
(UTILITY)
2
1
225A
224A
13A
0
14
TB
0
14
14
351
14
56
86
1 2 3 4 5
J2
J1
CONTROL
DSW
1 2 3 4
