Generac Power Systems 04389-0 Installation And Owner's Manual page 37

ITEM PART NO. QTY.
1 0A9947E 1
0A9947F 1
0A9947C 1
2 0A18010SRV 1
3 0830490SRV 1
4 0C2174 2
0C2174 1
5 075210A 1
6 0D3062 4
7 0C62110SRV 1
0C6211ASRV 1
8 032300 2
9 022676 1
10 033873 1
11 0A2769 1
12 023484E 1
13 075476 2
14 022264 6
15 051715 6
16 043182 8
043182 6
17 043181 8
043181 6
18 0D7618 1
19 054502 1
053623 1
20 0C6002A 1
0D2985 1
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
DESCRIPTION
CIRCUIT BREAKER 30 X 2 240V
SQD QOU230 (7KW)
CIRCUIT BREAKER 50 X 2 240V
SQD QOU245 (12KW)
CIRCUIT BREAKER 60 X 2 240V
SQD QOU260 (13KW)
ASSEMBLY, BATTERY CHARGER ENGINE
ASSEMBLY, POTTED REGULATOR W/FIN
RELAY, 12V 25A SPST (12KW / 15KW)
RELAY, 12V 25A SPST (7KW)
TERMINAL BLOCK
HEX. STAND-OFF #6-32 X 3/8"
ASSEMBLY, HOME STANDBY CONTROLLER
(12KW / 15KW)
ASSEMBLY, HOME STANDBY CONTROLLER
(7KW)
HOLDER, FUSE
FUSE, 15 AMP X AGC15
SWITCH, ROCKER
LUG, GROUND 8-TABS
SNAP BUSHING
SCREW PPHM M4-0.7 X 16
WASHER LOCK M4
NUT HEX M4-0.7 G8 YELLOW CHROME
WASHER LOCK M3 (12KW / 15KW)
WASHER LOCK M3 (7KW)
SCREW PHM M3-0.5 X 10 (12KW / 15KW)
SCREW PHM M3-0.5 X 10 (7KW)
DECAL, CONTROL PANEL (NOT SHOWN)
CIRCUIT BREAKER 3 X 1 ETA 46-500-P
(12KW / 15KW)
CIRCUIT BREAKER 2.5 X 1 ETA 46-500-P
(7KW)
CONTROL, PANEL BOTTOM (12KW / 15KW)
CONTROL, PANEL BOTTOM (7KW)
Section 7 — Exploded Views and Parts Lists
Control Panel – Drawing No. 0D3418-D
ITEM PART NO.
21 075235
22 0D5240
23 051714
24 0C1457
25 036261
26 0C7756
0D5831
27 074908
28 049226
29 051716
30 0C3910
31 031879
031879
32 099727
33 0C3701
34 063617
35 075475
36 022985
37 0C6002C
0D2988
38 092036
39 045770
40 0C7171
0D2989
41 0D3700
42 0912970069
43 0A2311
44 0A1658
45 022473
QTY. DESCRIPTION
4 SCREW HHC M5-0.8 X 30 G8.8
1 SWITCH, SPDT (ON)-ON N/D
8 NUT HEX M3-0.5 G8 YELLOW CHROME
1 HOURMETER
2 RIVET POP .125 X .129-.133/#30
1 HARNESS, CONTROL PANEL WIRE
(NOT SHOWN) (12KW / 15KW)
1 HARNESS, CONTROL PANEL WIRE
(NOT SHOWN) (7KW)
4 SCREW TAPTITE, M5-0.8 X 10 BP
(12KW / 15KW)
6 WASHER LOCK M5
6 NUT HEX M5-0.8 G8 YELLOW CHROME
1 TRANSFORMER 240/16V 1VA&56VA
6 WASHER FLAT #4 ZINC (12KW / 15KW)
4 WASHER FLAT #4 ZINC (7KW)
1 FUSE 5A X AGC5
1 DIN RAIL ASSEMBLY
1 RELAY PANEL 12VDC DPDT 10A@240VA
4 SCREW PPHM M4-0.7 X 10
2 WASHER FLAT #6 ZINC
1 COVER, CONTROL PANEL COMPONENT
(12KW / 15KW)
1 COVER, CONTROL PANEL COMPONENT
(7KW)
8 SCREW PPHMS/LW 6-32 X 1/4L
2 SCREW HHC M5-0.8 X 10 G8.8
1 COVER, CONTROL PANEL (12KW / 15KW)
1 COVER, CONTROL PANEL (7KW)
10 NUT FLANGE M6-1.0 NYLOK
1 ASSEMBLY, ROOF/DOOR GROUND WIRE
1 SCREW SWAGE 1/4-20 X 1 Z/YC
1 L/WASH SPECIAL 1/4"
1 WASHER FLAT 1/4 ZINC
Generac Power Systems, Inc. 35
®
